Engines · R series
S6R Inline-6 Propulsion / Diesel-Electric / Genset
Applications Propulsion / Diesel-Electric Propulsion / Auxiliary Genset
Output 324–691 kW
Output 434–927 bhp
Displacement 24.51 L
Cylinders 6
Configuration Inline-6
Bore × stroke 170 × 180 mm
Dry weight 2,950 kg
Dimensions (L×W×H) 2122 × 1201.5 × 1615 mm
EIAPP IMO II Compliant
Class approvals NK, LR, BV, ABS, DNV-GL Mid-range six-cylinder high-speed diesel covering propulsion, diesel-electric
propulsion and auxiliary genset duty, sharing its architecture with the
larger-displacement S6R2.
Full ratings by duty
Propulsion 324–691 kW · 1600–1800 rpm
Variant kW bhp rpm Rating Cooling Emissions
S6R-MPTK Not sold new → 405 543 1600 UCD Intercooler, sea water Not regulated S6R-MPTK Not sold new → 441 591 1600 UCD Intercooler, sea water Not regulated S6R-MPTK Not sold new → 470 630 1600 UCD Intercooler, sea water Not regulated S6R-MPTAW Not sold new → 324 434 1600 UCD Intercooler, fresh water IMO Tier II S6R-MPTAW Not sold new → 447 599 1600 UCD Intercooler, fresh water IMO Tier II S6R-MPTAW Not sold new → 470 630 1600 UCD Intercooler, fresh water IMO Tier II S6R-MPTAW Not sold new → 520 697 1650 HD Intercooler, fresh water IMO Tier II S6R-MPTAW Not sold new → 605 811 1800 MD Intercooler, fresh water IMO Tier II S6R-T2MPTK 470 630 1600 UCD Intercooler, sea water IMO Tier II
S6R-T2MPTK 520 697 1650 HD Intercooler, sea water IMO Tier II
S6R-T2MPTK 605 811 1800 MD Intercooler, sea water IMO Tier II
S6R-T2MPTK2 610 818 1637 HD Intercooler, sea water IMO Tier II
S6R-T2MPTK2 691 927 1696 MD Intercooler, sea water IMO Tier II
Not sold new configurations don't meet IMO Tier II, which Australian rules require for new marine engines sold here. OPS still stocks genuine parts for them and can supply the Tier II equivalent.
Diesel-Electric Propulsion 545–577 kW · 1500–1800 rpm
Variant kW bhp rpm Hz Cooling Emissions
S6R-MPTAW Not sold new → 545 731 1500 50 Intercooler, fresh water IMO Tier II (SCR25) S6R-MPTAW Not sold new → 577 774 1800 60 Intercooler, fresh water IMO Tier II (SCR25) Not sold new configurations don't meet IMO Tier II, which Australian rules require for new marine engines sold here. OPS still stocks genuine parts for them and can supply the Tier II equivalent.
Auxiliary Genset 515–635 kW · 1500–1800 rpm
Variant kW bhp rpm Hz Cooling Emissions
S6R-MPTAW Not sold new → 545 731 1500 50 Intercooler, fresh water IMO Tier II (SCR25) S6R-MPTAW Not sold new → 635 852 1800 60 Intercooler, fresh water IMO Tier II (SCR25) Not sold new configurations don't meet IMO Tier II, which Australian rules require for new marine engines sold here. OPS still stocks genuine parts for them and can supply the Tier II equivalent.
Rating codes
UCD Unrestricted Continuous DutyFull-load operation allowed unlimited, unlimited hours per year. Cargo vessels and fishing boats.
HD Heavy DutyUp to 83% load, full load for 8 hrs per 24 hrs, under 6,000 hrs/year. Working, fishing, tug and ferry boats, passenger vessels.
MD Medium DutyUp to 75% load, full load for 1 hr per 6 hrs, under 4,000 hrs/year. Pleasure and patrol boats, high-performance vessels. An S6R-T2MPTK unit at OPS's Wangara warehouse. Parts for the S6R
Genuine MHI parts stocked in Wangara WA, with a regional supply hub in Singapore.
Parts for this model Parts catalogue — S6R-T2MPTK
1,948 parts across 115 assembly groups, extracted from MHI's own parts catalogue (Pub. No. 282T0-00921_00, 2020-06-27). Grouped and ordered to match the catalogue's own table of contents.
Not sure which model your part belongs to? Search all five catalogues at once →
No parts match that search.
Service kits
The kits most customers order routinely, pulled out from the full catalogue below.
P48A1-920 PUMP ASSY (OVERHAUL KIT) 29 parts
Ref Part No. Name Qty 2050 48202-59902 GASKET KIT,OVERHAUL 1 Enquire → 2050010 48202-13501 BELLOWS, WITHOUT BAND 2 Enquire → 2050020 48202-23500 BELLOWS, WITH BAND 2 Enquire → 2050030 48202-08201 BAND,BELLOWS 2 Enquire → 2050040 48202-08301 BAND,BELLOWS 2 Enquire → 2050050 48202-14100 SHIM,CASE, T=0.50 4 Enquire → 2050060 48202-14200 SHIM,CASE, T-0.10 1 Enquire → 2050070 48202-14300 SHIM,CASE, T=0.15 1 Enquire → 2050080 48202-14400 SHIM,CASE, T-0.30 2 Enquire → 2050090 * SHIM SET,BARREL 1 Enquire → 2050100 05946-00801 WASHER,SEALING 3 Enquire → 2050110 05946-01001 WASHER,SEALING 12 Enquire → 2050120 05946-01201 WASHER,SEALING 13 Enquire → 2050130 05946-01401 WASHER,SEALING 6 Enquire → 2050140 48202-07100 SEAL,OIL 1 Enquire → 2050150 48202-12400 O-RING 18 Enquire → 2050160 05507-10080 O-RING 2 Enquire → 2050170 05507-20350 O-RING 1 Enquire → 2050180 05507-20800 O-RING 2 Enquire → 2050190 05507-20250 O-RING 6 Enquire → 2050200 48202-09200 SLEEVE 1 Enquire → 2050210 48202-05800 WIRE 1 Enquire → 2050220 48202-07700 SEAL 1 Enquire → 2050230 05507-10360 O-RING 1 Enquire → 2050240 05946-02701 WASHER,SEALING 1 Enquire → 2050250 05507-10390 O-RING 1 Enquire → 2050260 37564-05200 NUT,TAMPER PROOF 2 Enquire → 2050270 F1035-08045 BOLT 2 Enquire → 3000 48202-09200 SLEEVE 1 Enquire →
P3751-940-02 OVERHAUL GASKET KIT (MARINE USE) 3 parts
Ref Part No. Name Qty 0010 37594-43150 GASKET KIT,OVERHAUL, MARINE ENGINE 1 Enquire → 0100 37594-43220 GASKET KIT,OVERHUAL, COMMON USE 1 Enquire → 0300 37594-58131 GASKET KIT,OVERHUAL, MARINE ADD. PARTS 1 Enquire →
P3751-940-03 OIL SEAL KIT 10 parts
Ref Part No. Name Qty 0080 37594-42140 SEAL KIT,OIL 1 Enquire → 0080010 37511-04300 SEAL,OIL 2 Enquire → 0080020 37539-00600 SEAL,THERMOSTAT 1 Enquire → 0080030 37545-30600 SEAL,UNIT 1 Enquire → 0080040 F3003-01831 SEAL,OIL 2 Enquire → 0080050 37525-13400 SEAL,OIL 1 Enquire → 0080060 37548-00900 SEAL,OIL 1 Enquire → 0080070 37545-01300 SEAL,OIL 1 Enquire → 0080080 37545-01400 SEAL,OIL 1 Enquire → 0080090 37546-01800 SEAL,OIL 2 Enquire →
P3751-940-04 REPAIR KIT (WATER PUMP) 12 parts
Full parts list, by assembly group
P3751-010 CYLINDER HEAD 18 parts
Ref Part No. Name Qty 0300 * HEAD SUB ASSY,CYLINDER 6 Enquire → 0300010 * HEAD,CYLINDER 6 Enquire → 0300030 * SEAT,VALVE, SEMIFINISHED 24 Enquire → 0300040 * GUIDE,VALVE, SEMIFINISHED 24 Enquire → 0300050 04826-22800 CAP,SEALING 42 Enquire → 0300060 04826-22500 CAP,SEALING 6 Enquire → 0300070 04827-71000 PLUG,TAPERED 6 Enquire → 0500 37501-80050 HEAD ASSY,CYLINDER 6 Enquire → 0900 33501-13400 GUIDE 12 Enquire → 1100 37501-11401 STUD,NOZZLE GLAND 6 Enquire → 1150 37501-01501 PIN,DOWEL 6 Enquire → 1200 37501-12200 GASKET,CYLINDER 6 Enquire → 1300 37501-12501 BOLT,CYLINDER HEAD 36 Enquire → 1350 33707-11701 WASHER 36 Enquire → 2000 37101-10600 GUIDE,VALVE, FINISHED 24 Enquire → 2100 37501-13100 SEAT,VALVE, FINISHED 24 Enquire → 2110 37501-14200 SEAT,VALVE, O.S 0.03 AR Enquire → 2120 37501-14300 SEAT,VALVE, O.S 0.06 AR Enquire →
P3751-040 VALVE MECHANISM 42 parts
Ref Part No. Name Qty 0300 37504-03801 VALVE,INLET 12 Enquire → 0305 37504-40200 VALVE,EXHAUST 12 Enquire → 0400 32504-00400 COTTER 48 Enquire → 0500 37504-00300 ROTATOR 12 Enquire → 0510 38C04-01300 ROTATOR,DOUBLE SPRING 12 Enquire → 0600 37504-10400 SPRING,VALVE 12 Enquire → 0610 37504-10600 SPRING,VALVE, INNER 12 Enquire → 0620 37504-10802 RETAINER,EXHAUST, LOWER 12 Enquire → 0630 37504-20500 SPRING,VALVE, OUTER 12 Enquire → 0700 33504-10300 SEAL,VALVE STEM 12 Enquire → 0710 37504-00900 SEAL,VALVE STEM 12 Enquire → 0800 * BRIDGE ASSY,EXHAUST 6 Enquire → 0800010 37504-03400 BRIDGE,EXHAUST 6 Enquire → 0800020 37704-03300 SCREW,ADJUSTING 6 Enquire → 0800030 F2305-10000 NUT 6 Enquire → 0900 * BRIDGE ASSY,INLET 6 Enquire → 0900010 37504-03500 BRIDGE,INLET 6 Enquire → 0900020 37704-03300 SCREW,ADJUSTING 6 Enquire → 0900030 F2305-10000 NUT 6 Enquire → 1200 30004-24302 CAP 12 Enquire → 1500 * ROCKER & SHAFT ASSY 6 Enquire → 1500010 37504-05011 ROCKER ASSY 12 Enquire → 1500020 * ARM,ROCKER 12 Enquire → 1500030 37504-05200 BUSHING,ROCKER 12 Enquire → 1500040 37104-02800 SCREW,ADJUSTING 12 Enquire → 1500050 F2305-12000 NUT 12 Enquire → 1500060 37504-05032 SHAFT ASSY,ROCKER 6 Enquire → 1500070 * SHAFT,ROCKER 6 Enquire → 1500080 04826-21000 CAP,SEALING 6 Enquire → 1500090 37504-04300 SPACER,ROCKER 6 Enquire → 1800 37504-51102 CASE,ROCKER 6 Enquire → 1900 37504-41200 PACKING,ROCKER CASE 6 Enquire → 1950 F2846-06000 PIN,DOWEL 6 Enquire → 2000 MC802397 BOLT 30 Enquire → 2100 37504-02300 O-RING 6 Enquire → 2200 05507-10200 O-RING 6 Enquire → 2300 37501-01501 PIN,DOWEL 6 Enquire → 2700 MH000854 BOLT,FLANGE 6 Enquire → 2800 37504-14600 BOLT 6 Enquire → 2900 37504-26102 COVER,ROCKER 6 Enquire → 3000 37504-66200 O-RING,ROCKER COVER 6 Enquire → 3100 F1825-10065 BOLT,W/WASHER, B/W 17 Enquire →
P3751-050 CAMSHAFT TAPPET 7 parts
P3751-070-01 CYLINDER CRANKCASE (ASSY) 27 parts
Ref Part No. Name Qty 0200 * CRANNKCASE SUB ASSY 1 Enquire → 0200010 * CRANKCASE,CYLINDER 1 Enquire → 0200270 * CAP,BEARING NO.1-6 6 Enquire → 0200280 * CAP,BEARING NO.7 1 Enquire → 0210 33707-11701 WASHER 28 Enquire → 0220 37507-31601 BOLT,BEARING CAP 28 Enquire → 0300 37507-60022 CRANKCASE ASSY 1 Enquire → 0800 33007-02600 PIN,DOWEL 6 Enquire → 1100 37807-02600 PIN,DOWEL 12 Enquire → 1200 04827-72100 PLUG,TAPERED 1 Enquire → 1270 04827-71300 PLUG,TAPERED 3 Enquire → 1280 04826-22500 CAP,SEALING 1 Enquire → 1290 04827-71300 PLUG,TAPERED 1 Enquire → 1700 37507-23100 BUSHING,CAMSHAFT 1 Enquire → 1750 37707-03101 BUSHING,CAMSHAFT 1 Enquire → 1800 37707-03201 BUSHING,CAMSHAFT 5 Enquire → 1900 37507-03901 BOLT,SET 7 Enquire → 2000 05946-01201 WASHER,SEALING 7 Enquire → 2100 37507-04600 PIN,DOWEL 2 Enquire → 2600 F2846-20000 PIN,DOWEL 2 Enquire → 2700 37507-00703 PLATE,NOZZLE 1 Enquire → 2800 05507-10340 O-RING 1 Enquire → 2900 04827-71300 PLUG,TAPERED 1 Enquire → 3000 F2846-14000 PIN,DOWEL 2 Enquire → 3050 04826-24000 CAP,SEALING 1 Enquire → 3060 32625-00800 CAP,SEALING 1 Enquire → 3100 F2846-12000 PIN,DOWEL 2 Enquire →
P3751-070-02 CYLINDER CRANKCASE (LINER) 7 parts
Ref Part No. Name Qty 1300 37507-22700 LINER,CYLINDER 6 Enquire → 1400 37507-12500 RING,LINER, T=0.10 AR Enquire → 1410 37507-12510 RING,LINER, T=0.05 AR Enquire → 1420 37507-12520 RING,LINER, T=0.15 AR Enquire → 1450 37507-32400 O-RING,LINER 6 Enquire → 1500 37107-04201 O-RING,LINER 6 Enquire → 1600 37107-04300 O-RING,LINER 12 Enquire →
P3751-071 CRANKCASE PARTS 52 parts
Ref Part No. Name Qty 0160 37507-01401 HANGER,REAR 1 Enquire → 0170 F1035-16040 BOLT 2 Enquire → 0180 F2515-16000 WASHER,SPRING 2 Enquire → 0200 F1035-12035 BOLT 3 Enquire → 0210 F2515-12000 WASHER,SPRING 3 Enquire → 0300 37507-27101 COVER,SIDE 2 Enquire → 0350 37507-16901 COVER,SIDE 1 Enquire → 0380 37507-08702 COVER,SIDE 1 Enquire → 0382 36207-03500 COVER 1 Enquire → 0384 33442-20200 PACKING 1 Enquire → 0386 F1805-10025 BOLT,W/WASHER, B/W 2 Enquire → 0400 37507-16401 O-RING,SIDE COVER 5 Enquire → 0420 37707-27200 PACKING,SIDE COVER 1 Enquire → 0500 F1825-12030 BOLT,W/WASHER, B/W 20 Enquire → 0501 F1825-12040 BOLT,W/WASHER, B/W 4 Enquire → 0650 37507-37800 COVER,CAM ROOM 3 Enquire → 0700 37507-16501 O-RING,CAM ROOM 3 Enquire → 0800 37507-16301 COVER,CAM ROOM 1 Enquire → 0850 37507-04900 PACKING,CAM ROOM 2 Enquire → 1050 F1825-12030 BOLT,W/WASHER, B/W 13 Enquire → 1052 F1035-12055 BOLT 1 Enquire → 1057 F1035-12030 BOLT 4 Enquire → 1060 F2515-12000 WASHER,SPRING 5 Enquire → 1150 37507-27201 COVER,SIDE 1 Enquire → 1155 08900-01901 BUSHING 1 Enquire → 1180 37507-28900 COVER,CAM ROOM 1 Enquire → 1200 37507-20401 NOZZLE,OIL JET 6 Enquire → 1500 36207-58901 VALVE,CHECK 6 Enquire → 1600 36207-08900 SPRING CONICAL DISK 6 Enquire → 1700 33407-16100 COCK,WATER DRAIN 1 Enquire → 1710 05946-02001 WASHER,SEALING 1 Enquire → 1800 30007-05500 CLAMP 1 Enquire → 1900 F4002-12120 TUBE,SOFT VINYL 1 Enquire → 2000 33546-06900 COVER 2 Enquire → 2020 37545-18700 PLATE,TENSION 1 Enquire → 2040 F1805-12025 BOLT,W/WASHER, B/W 3 Enquire → 2100 35B36-02900 GASKET,OIL 2 Enquire → 2120 37507-06700 COVER 1 Enquire → 2140 05507-20400 O-RING 1 Enquire → 2200 F1805-12025 BOLT,W/WASHER, B/W 6 Enquire → 2300 F5005-10001 PLUG,TAPERED 1 Enquire → 2350 F5006-13000 PLUG,TAPERED 2 Enquire → 2400 37508-00500 CONNECTOR 1 Enquire → 2500 45954-30100 PIPE,OIL 1 Enquire → 3100 37707-09300 COVER 1 Enquire → 3110 F5006-10000 PLUG,TAPERED 2 Enquire → 3200 37555-10600 GASKET,AIR 1 Enquire → 3300 F1805-12025 BOLT,W/WASHER, B/W 2 Enquire → 3500 04827-71000 PLUG,TAPERED 1 Enquire → 3600 32607-10700 PLUG 1 Enquire → 3700 05507-10340 O-RING 1 Enquire → 3800 04826-22000 CAP,SEALING 1 Enquire →
P3751-072 CRANKCASE GOVERNOR PARTS 7 parts
P3751-090 MAIN BEARING 11 parts
Ref Part No. Name Qty 0100 * BEARING,MAIN, UPPER 7 Enquire → 0200 * BEARING,MAIN, LOWER 7 Enquire → 0300 37509-38100 BEARING,THRUST, STD 4 Enquire → 0710 37509-38200 BEARING,THRUST, O.S. 0.25 4 Enquire → 0720 37509-38300 BEARING,THRUST, O.S. 0.50 4 Enquire → 0730 37509-38400 BEARING,THRUST, O.S. 0.75 4 Enquire → 0810 37509-50010 BEARING SET,MAIN, STD 7 Enquire → 0820 37509-50020 BEARING SET,MAIN, U.S. 0.25 7 Enquire → 0830 37509-50030 BEARING SET,MAIN, U.S. 0.50 7 Enquire → 0840 37509-50040 BEARING SET,MAIN, U.S. 0.75 7 Enquire → 0850 37509-50050 BEARING SET,MAIN, U.S. 1.00 7 Enquire →
P3751-110 TIMING GEAR CASE 24 parts
Ref Part No. Name Qty 0100 37511-90100 CASE,TIMING GEAR 1 Enquire → 0110 37411-02300 PLUG 1 Enquire → 0350 36211-03100 COVER 1 Enquire → 0400 F1805-12020 BOLT,W/WASHER, B/W 3 Enquire → 0500 F2846-14000 PIN,DOWEL 4 Enquire → 0700 37511-30200 PACKING 1 Enquire → 0800 37511-60300 PLATE,REAR 1 Enquire → 0900 37511-30400 PACKING 1 Enquire → 1000 05978-16125 BOLT 9 Enquire → 1100 F1035-16085 BOLT 3 Enquire → 1150 F1035-16080 BOLT 2 Enquire → 1200 F2305-16000 NUT 2 Enquire → 1300 31201-71800 WASHER 14 Enquire → 1400 F1035-12030 BOLT 12 Enquire → 1500 37525-07901 WASHER 12 Enquire → 1550 * OIL SEAL ASSY,REAR 1 Enquire → 1600 37111-14200 SLINGER 1 Enquire → 1700 37511-04300 SEAL,OIL 1 Enquire → 1800 37511-09100 PLUG 1 Enquire → 1900 37511-23101 COVER 1 Enquire → 2000 37511-13200 PACKING 1 Enquire → 2100 F1805-10020 BOLT,W/WASHER, B/W 3 Enquire → 2500 F5000-24000 PLUG,DRAIN 1 Enquire → 2600 05946-02401 WASHER,SEALING 1 Enquire →
P3751-130-01 OIL PAN (WITH INSPECTION WINDOW) 16 parts
Ref Part No. Name Qty 0200 37513-10200 PACKING,OIL PAN 1 Enquire → 0300 F1805-12035 BOLT,W/WASHER, B/W 41 Enquire → 0400 33546-06900 COVER 3 Enquire → 0500 05507-20600 O-RING 2 Enquire → 0550 05507-20500 O-RING 1 Enquire → 0600 F1805-12025 BOLT,W/WASHER, B/W 6 Enquire → 0650 F5006-17000 PLUG,TAPERED 1 Enquire → 0700 F5000-36000 PLUG,DRAIN 2 Enquire → 0800 05946-03601 WASHER,SEALING 2 Enquire → 0900 F5000-20000 PLUG,DRAIN 2 Enquire → 1000 05946-02001 WASHER,SEALING 2 Enquire → 2100 37513-20603 PAN,OIL 1 Enquire → 2400 37213-00400 COVER, L.H 1 Enquire → 2500 37513-03200 COVER, R.H 1 Enquire → 2600 37213-10700 PACKING 2 Enquire → 2700 F1805-10020 BOLT,W/WASHER, B/W 40 Enquire →
P3751-130-02 OIL PAN (WITH OUT INSPECTION WINDOW) 9 parts
P3751-140 MOUNTING BRACKET 9 parts
P3751-170 PISTON 7 parts
P3751-190 CONNECTING ROD 9 parts
Ref Part No. Name Qty 0110 * ROD ASSY,CONNECTING, BEFORE WEIGHT ADJUST 6 Enquire → 0110010 * ROD,CONNECTING 6 Enquire → 0110020 * CAP,CONNECTING ROD 6 Enquire → 0110030 37519-21301 BOLT,CONNECTING ROD, SHORT 6 Enquire → 0110040 37519-11401 BOLT,CONNECTING ROD, LONG 6 Enquire → 0110050 * BUSHING,CON-ROD, SEMIFINISHED 6 Enquire → 1100 37519-13100 BEARING,CON-ROD 12 Enquire → 1200 37519-10600 BUSHING,CON-ROD, FINISHED 6 Enquire → 3100 37519-31021 ROD ASSY,CONNECTING, RANK M:16.15KG 6 Enquire →
P3751-200 CRANKSHAFT 7 parts
P3751-210 FLYWHEEL 5 parts
P3751-220 DAMPER 11 parts
Ref Part No. Name Qty 0001 * LABEL SET,THERMO, INCLUDES 20 PIECE 1 Enquire → 0001010 32522-04111 LABEL,THERMO, 75℃ TO 95℃ 1 Enquire → 0002 * LABEL SET,THERMP, INCLUDES 20 PIECE 1 Enquire → 0002010 32522-04211 LABEL,THERMO, 100℃ TO 120℃ 1 Enquire → 0003 * LABEL SET,THERMO, INCLUDES 20 PIECE 1 Enquire → 0003010 32522-04311 LABEL,THERMO, 50℃ TO 70℃ 1 Enquire → 0200 37522-10500 DAMPER 1 Enquire → 0300 37522-05200 POINTER 1 Enquire → 0400 F1805-10016 BOLT,W/WASHER, B/W 1 Enquire → 0410 F1825-10035 BOLT,W/WASHER, B/W 1 Enquire → 0420 F2500-10000 WASHER,PLAIN 1 Enquire →
P3751-230 TIMING GEAR 11 parts
P3751-250-01 FRONT ACCESSORY DRIVE 17 parts
Ref Part No. Name Qty 0200 37525-70100 COVER,FRONT 1 Enquire → 0300 37525-40200 PACKING,FRONT COVER 1 Enquire → 0400 F1805-12035 BOLT,W/WASHER, B/W 2 Enquire → 0405 F1805-12040 BOLT,W/WASHER, B/W 2 Enquire → 0410 F1035-12045 BOLT 2 Enquire → 0415 F2515-12000 WASHER,SPRING 2 Enquire → 0420 F2846-14000 PIN,DOWEL 2 Enquire → 0460 * SEAL ASSY,OIL, FRONT 1 Enquire → 0500 37425-08201 SLINGER,FRONT 1 Enquire → 0600 37511-04300 SEAL,OIL 1 Enquire → 0750 37525-12202 PULLEY,CRANKSHAFT 1 Enquire → 0900 33707-11701 WASHER 8 Enquire → 1340 F1805-12035 BOLT,W/WASHER, B/W 4 Enquire → 1600 05507-20900 O-RING 1 Enquire → 1700 F1805-12035 BOLT,W/WASHER, B/W 4 Enquire → 3100 37525-28101 PULLEY,CRANK, 2-BELT 1 Enquire → 3250 05978-22180 BOLT 8 Enquire →
P3751-250-02 FRONT ACCESSORY DRIVE (BELT COVER) 12 parts
P3751-251 TACHOMETER 1 part
Ref Part No. Name Qty 0920 37525-07500 COVER 1 Enquire →
P3751-253 REAR ACCESSORY DRIVE 16 parts
Ref Part No. Name Qty 0100 37525-63100 CASE,DRIVE 1 Enquire → 0200 37525-03600 O-RING 1 Enquire → 0300 F1035-12045 BOLT 7 Enquire → 0400 37525-07901 WASHER 7 Enquire → 0500 F1035-12035 BOLT 1 Enquire → 0510 37525-07901 WASHER 1 Enquire → 0600 37525-24101 SHAFT,DRIVE 1 Enquire → 0700 37725-15700 KEY,SUNK 1 Enquire → 0750 F2870-10032 KEY,WOODRUFF 1 Enquire → 0800 37525-00600 WASHER,DRIVE SHAFT 1 Enquire → 0950 37525-09900 NUT 1 Enquire → 1000 F8010-06309 BEARING,BALL 1 Enquire → 1100 F3202-10000 RING,SNAP 1 Enquire → 1200 F8006-06210 BEARING,BALL 1 Enquire → 1300 37525-13400 SEAL,OIL, WITH DUST LIP 1 Enquire → 1400 04827-71300 PLUG,TAPERED 1 Enquire →
P3751-255 HOURMETER 5 parts
P3751-300 INLET SYSTEM 7 parts
P3751-303-01 AIR CLEANER (FOR TD13 TURBOCHARGER) 3 parts
P3751-303-02 AIR CLEANER (FOR TF15 TURBOCHARGER) 10 parts
P3751-305 AIR HEATER & SPACER 4 parts
P3751-320-01 EXHAUST MANIFOLD (FOR TD13 TURBOCHARGER) 19 parts
Ref Part No. Name Qty 0300 37532-09500 GASKET 6 Enquire → 0310 37532-07900 BOLT,FLANGE 12 Enquire → 0330 37532-12900 BOLT,FLANGE 12 Enquire → 0340 37768-03602 SPACER 12 Enquire → 0350 37532-09900 WASHER 12 Enquire → 1000 F2440-12000 NUT,SELF LOCKING 4 Enquire → 5000 37532-40025 MANIFOLD ASSY,EXHAUST 1 Enquire → 5000010 * MANIFOLD,EXHAUST 1 Enquire → 5000020 04826-23000 CAP,SEALING 9 Enquire → 5000030 37N32-04100 PLUG,SCREW 6 Enquire → 5000040 41232-03900 GASKET 6 Enquire → 5060 37532-02601 COVER,EXHAUST 1 Enquire → 5070 37532-12700 PACKING 1 Enquire → 5080 F1805-10025 BOLT,W/WASHER, B/W 4 Enquire → 5100 35A32-00300 STUD,TURBO 4 Enquire → 5600 33407-16100 COCK,WATER DRAIN 1 Enquire → 5800 37552-01200 PIPE,DRAIN COCK 1 Enquire → 5900 30007-05500 CLAMP 1 Enquire → 6000 35A46-09400 CLAMP 1 Enquire →
P3751-320-02 EXHAUST MANIFOLD (FOR TF15 TURBOCHARGER) 22 parts
Ref Part No. Name Qty 0300 37532-09500 GASKET 6 Enquire → 0310 37532-07900 BOLT,FLANGE 12 Enquire → 0330 37532-12900 BOLT,FLANGE 12 Enquire → 0340 37768-03602 SPACER 12 Enquire → 0350 37532-09900 WASHER 12 Enquire → 0600 37532-01900 STAY 1 Enquire → 0610 F2005-12025 BOLT,W/WASHER, B/W 2 Enquire → 0620 F1805-12050 BOLT,W/WASHER, B/W 2 Enquire → 1000 F2440-12000 NUT,SELF-LOCKING 4 Enquire → 5050 37532-40035 MANIFOLD ASSY,EXHAUST 1 Enquire → 5050010 * MANIFOLD,EXHAUST 1 Enquire → 5050020 04826-23000 CAP,SEALING 9 Enquire → 5050030 37N32-04100 PLUG,SCREW 6 Enquire → 5050040 41232-03900 GASKET 6 Enquire → 5060 37532-02601 COVER,EXHAUST MANIFOLD 1 Enquire → 5070 37532-12700 PACKING 1 Enquire → 5080 F1805-10025 BOLT,W/WASHER, B/W 4 Enquire → 5100 35A32-00300 STUD,TURBO 4 Enquire → 5600 33407-16100 COCK,WATER DRAIN 1 Enquire → 5800 37552-01200 PIPE,DRAIN COCK 1 Enquire → 5900 30007-05500 CLAMP 1 Enquire → 6000 35A46-09400 CLAMP 1 Enquire →
P3751-321-01 EXHAUST PIPE (FOR TD13 TURBOCHARGER) 13 parts
P3751-321-02 EXHAUST PIPE (FOR TF15 TURBOCHARGER) 13 parts
P375B-323 EXHAUST COVER (WITH EXHAUST COVER SPEC.) 4 parts
Ref Part No. Name Qty 1900 45R32-10500 LAGGING,TURBOCHARGER 2 Enquire → 1920 45R32-10600 LAGGING,EXHAUST PIPE 1 Enquire → 1930 45R32-11200 LAGGING,BRACKET 1 Enquire → 1950 45R32-11901 LAGGING,MANIFOLD 6 Enquire →
P3751-330 TURBOCHARGER(TD13L,TF15M1)) 4 parts
Ref Part No. Name Qty 0110 49129-02060 TURBOCHARGER ASSY, FOR TF15 T/C 1 Enquire → 0207 49182-06170 TURBOCHARGER ASSY, FOR TD13 T/C 1 Enquire → 0300 37533-03100 GASKET,TURBOCHARGER, FOR TF15 T/C 1 Enquire → 0500 35A32-30100 GASKET,TURBOCHARGER, FOR TD13 T/C 1 Enquire →
P4913-000 TURBOCHARGER ASSY (TD13, CARTRIDGE ASSY) 18 parts
Ref Part No. Name Qty 0100 49181-22200 DEFLECTOR,OIL 1 Enquire → 0200 49181-21100 BEARING 2 Enquire → 0300 49181-21600 BEARING,THRUST 1 Enquire → 0400 49181-42400 RING,THRUST 1 Enquire → 0500 49181-42300 RING,THRUST 1 Enquire → 0600 49181-42100 SLEEVE,FINGER 1 Enquire → 0700 49181-22500 INSERT 1 Enquire → 0800 49181-22600 O-RING,INSERT 1 Enquire → 0900 49181-22300 RING,SNAP 3 Enquire → 1000 49162-23202 RING,SNAP 1 Enquire → 1100 49181-23100 RING,PISTON 2 Enquire → 1211 49181-42241 NUT,LOCK 1 Enquire → 1300 49182-19300 PLATE,BACK TURBINE 1 Enquire → 1720 * HOUSING,BEARING 1 Enquire → 2300 49183-22800 PIN,SPRING 1 Enquire → 3000 49182-30130 ROTOR ASSY 1 Enquire → 6130 49182-45120 WHEEL,COMPERESSOR 1 Enquire → 9900 49182-25640 HOUSING ASSY,BRG 1 Enquire →
P4913-100 TURBOCHARGER ASSY (TD13, COMPRESSOR COVER) 6 parts
P4913-200 TURBOCHARGER ASSY (TD13, TURBINE HOUSING) 4 parts
P4933-000 TURBOCHARGER ASSY (TF15, CARTRIDGE ASSY) 19 parts
Ref Part No. Name Qty 0100 49129-19100 PLATE,BACK TURBINE 1 Enquire → 0200 49127-21500 BEARING,THRUST 1 Enquire → 0300 49127-21400 DEFLECTOR,OIL 1 Enquire → 0400 49127-43300 SLEEVE,FLINGER 1 Enquire → 0500 49129-23100 RING,SNAP 1 Enquire → 0600 49127-21300 INSERT 1 Enquire → 0700 49162-23202 RING,SNAP 1 Enquire → 0810 49129-45101 NUT,LOCK 1 Enquire → 0900 49181-22600 O-RING,INSERT 1 Enquire → 1000 49127-42100 RING,THRUST 1 Enquire → 1100 49127-42200 RING,THRUST 1 Enquire → 1200 49129-22101 BEARING 2 Enquire → 1300 49127-23100 RING,PISTON 3 Enquire → 1400 49121-31701 RING,SEAL 1 Enquire → 1620 49129-30300 ROTOR ASSY 1 Enquire → 1815 * HOUSING,BEARING 1 Enquire → 1900 49183-22800 PIN,SPRING 2 Enquire → 2600 49129-40501 WHEEL,COMPRESSOR 1 Enquire → 9000 49129-25110 HOUSING ASSY,BEARING 1 Enquire →
P4933-100 TURBOCHARGER ASSY (TF15, COMPRESSOR COVER) 7 parts
P4933-200 TURBOCHARGER ASSY (TF15, TURBINE HOUSING) 4 parts
P3751-350 OIL PUMP 20 parts
Ref Part No. Name Qty 0100 37535-70010 PUMP ASSY,OIL 1 Enquire → 0100010 * CASE ASSY,OIL PUMP 1 Enquire → 0100020 * GEAR,HEAD, Z=32 1 Enquire → 0100030 * CASE SUB ASSY 1 Enquire → 0100060 * GEAR ASSY,DRIVE, Z=10 1 Enquire → 0100090 * PIN,DOWEL 2 Enquire → 0100100 37535-62010 COVER ASSY,OIL PUMP 1 Enquire → 0100120 37535-77010 GEAR ASSY,DRIVEN, Z=10 2 Enquire → 0100140 37535-64010 GEAR ASSY,IDLE, Z=35 1 Enquire → 0100160 37535-60800 SPINDLE 1 Enquire → 0100170 35A35-13200 VALVE,SAFETY 2 Enquire → 0100180 35A35-52100 SPRING,SAFETY VALVE 2 Enquire → 0100190 35A35-13300 STOPPER,SAFETY VALVE 2 Enquire → 0100200 35A35-13400 SEAT,SPRING 2 Enquire → 0100210 MF472087 PIN,SPLIT 2 Enquire → 0100220 MH004069 NUT,FLANGE 1 Enquire → 0100230 F1805-10035 BOLT,W/WASHER, B/W 4 Enquire → 0200 F1035-12100 BOLT 4 Enquire → 0300 F2515-12000 WASHER,SPRING 4 Enquire → 0400 37535-01100 SHIM, T=0.10 AR Enquire →
P3751-360 OIL STRAINER PIPING 18 parts
Ref Part No. Name Qty 0400 F1035-10080 BOLT 2 Enquire → 0500 F2515-10000 WASHER,SPRING 2 Enquire → 0510 05507-20650 O-RING 1 Enquire → 0600 37536-01201 SUPPORT,OIL PIPE 1 Enquire → 0800 F1805-12025 BOLT,W/WASHER, B/W 4 Enquire → 0900 37536-10200 PIPE,OIL 1 Enquire → 1000 F1035-10080 BOLT 2 Enquire → 1050 F2515-10000 WASHER,SPRING 2 Enquire → 1100 F1805-12030 BOLT,W/WASHER, B/W 2 Enquire → 1200 05507-20450 O-RING 1 Enquire → 1250 05507-20500 O-RING 1 Enquire → 2100 37536-38102 STRAINER,OIL 1 Enquire → 2200 37536-17700 SUPPORT 1 Enquire → 2300 F1035-10030 BOLT 1 Enquire → 2310 F2500-10000 WASHER,PLAIN 2 Enquire → 2320 F2515-10000 WASHER,SPRING 1 Enquire → 2330 F2300-10000 NUT 1 Enquire → 2400 F1825-10025 BOLT,W/WASHER, B/W 1 Enquire →
P3751-361 OIL FILTER PIPING 7 parts
Ref Part No. Name Qty 0100 37536-34020 RELIEF VALVE ASSY 1 Enquire → 0100010 37536-34200 VALVE,RELIEF 1 Enquire → 0100020 37536-14400 SPRING RELIEF VALVE 1 Enquire → 0100030 37536-34500 SLEEVE,RELIEF VALVE 1 Enquire → 0100040 37536-04800 PLATE RELIEF VALVE 1 Enquire → 0100050 37536-14700 STOPPER REL.VALVE 1 Enquire → 0190 05507-20450 O-RING 1 Enquire →
P3751-362-01 OIL SYSTEM PARTS (FOR TD13 TURBOCHARGER) 24 parts
Ref Part No. Name Qty 0170 F4610-16000 BOLT,EYE 1 Enquire → 0180 05946-01601 WASHER,SEALING 2 Enquire → 0225 F2005-10025 BOLT,W/WASHER, B/W 2 Enquire → 0310 F1805-12025 BOLT,W/WASHER, B/W 2 Enquire → 0320 37536-12700 PACKING,OIL 1 Enquire → 0500 35C36-02900 PACKING 1 Enquire → 0600 05507-20300 O-RING 1 Enquire → 0700 F1155-10040 BOLT 2 Enquire → 0800 F2515-10000 WASHER,SPRING 2 Enquire → 0900 37536-33100 PIPE,OIL 1 Enquire → 1000 F1805-10020 BOLT,W/WASHER, B/W 1 Enquire → 1200 37536-43300 PIPE,DRAIN 1 Enquire → 1400 F4610-12000 BOLT,EYE 1 Enquire → 1500 05946-01201 WASHER,SEALING 2 Enquire → 1600 F4610-14000 BOLT,EYE 1 Enquire → 1700 05946-01401 WASHER,SEALING 2 Enquire → 1800 37736-09500 STAY,OIL PIPE 1 Enquire → 1900 F1805-10020 BOLT,W/WASHER, B/W 1 Enquire → 2000 F2500-10000 WASHER,PLAIN 2 Enquire → 2100 F2005-10025 BOLT,W/WASHER, B/W 1 Enquire → 3000 37536-36100 PIPE,OIL 1 Enquire → 3065 37533-22200 PIPE,DRAIN 1 Enquire → 3200 F1805-12020 BOLT,W/WASHER, B/W 1 Enquire → 3250 F2500-12000 WASHER,PLAIN 1 Enquire →
P3751-362-02 OIL SYSTEM PARTS (FOR TF15 TURBOCHARGER) 25 parts
Ref Part No. Name Qty 0150 F2005-12025 BOLT,W/WASHER, B/W 1 Enquire → 0160 F2500-12000 WASHER,PLAIN 1 Enquire → 0170 F4610-16000 BOLT,EYE 1 Enquire → 0180 05946-01601 WASHER,SEALING 2 Enquire → 0225 F2005-10025 BOLT,W/WASHER, B/W 2 Enquire → 0310 F1805-12025 BOLT,W/WASHER, B/W 2 Enquire → 0320 37536-12700 PACKING,OIL 1 Enquire → 0500 35C36-02900 PACKING 1 Enquire → 0600 05507-20300 O-RING 1 Enquire → 0700 F1155-10040 BOLT 2 Enquire → 0800 F2515-10000 WASHER,SPRING 2 Enquire → 0900 37536-33100 PIPE,OIL 1 Enquire → 1000 F1805-10020 BOLT,W/WASHER, B/W 1 Enquire → 1200 37536-43300 PIPE,DRAIN 1 Enquire → 1400 F4610-12000 BOLT,EYE 1 Enquire → 1500 05946-01201 WASHER,SEALING 2 Enquire → 1600 F4610-14000 BOLT,EYE 1 Enquire → 1700 05946-01401 WASHER,SEALING 2 Enquire → 1800 37736-09500 STAY,OIL PIPE 1 Enquire → 1900 F1805-10020 BOLT,W/WASHER, B/W 1 Enquire → 2000 F2500-10000 WASHER,PLAIN 1 Enquire → 2900 37536-26801 PIPE,OIL 1 Enquire → 3060 37533-22100 PIPE,DRAIN 1 Enquire → 3200 F1805-12020 BOLT,W/WASHER, B/W 1 Enquire → 3250 F2500-12000 WASHER,PLAIN 1 Enquire →
P3751-362-03 OIL SYSTEM PARTS (EMERGENCY FILLER) 9 parts
P3751-390 OIL COOLER 27 parts
Ref Part No. Name Qty 0100 37539-40011 COOLER ASSY,OIL 1 Enquire → 0100010 37539-20100 ELEMENT,OIL COOLER 2 Enquire → 0100020 37539-30300 COVER,OIL COOLER 1 Enquire → 0100030 ME064526 PLUG 2 Enquire → 0100040 MH035093 O-RING 2 Enquire → 0100050 F5006-13000 PLUG,TAPERED 2 Enquire → 0100060 F5006-10000 PLUG,TAPERED 2 Enquire → 0100070 32639-09100 NUT,FLANGE 8 Enquire → 0100080 MH035626 O-RING 4 Enquire → 0100090 MH035092 O-RING 8 Enquire → 0200 37539-10200 PACKING,OIL COOLER 1 Enquire → 0300 37539-00400 O-RING 3 Enquire → 0400 F1825-12035 BOLT,W/WASHER, B/W 19 Enquire → 0450 F1825-12030 BOLT,W/WASHER, B/W 2 Enquire → 0500 37539-10500 THERMOSTAT,OIL 1 Enquire → 0600 37539-00600 SEAL,THERMOSTAT 1 Enquire → 0700 F5006-10000 PLUG,TAPERED 1 Enquire → 0800 F4540-08000 CONNECTOR 1 Enquire → 2000 37539-28101 COVER,OIL COOLER 1 Enquire → 2010 F5000-24000 PLUG,DRAIN 1 Enquire → 2020 05946-02401 WASHER,SEALING 1 Enquire → 2050 05507-10180 O-RING 1 Enquire → 2100 05507-20400 O-RING 1 Enquire → 2200 05507-20750 O-RING 1 Enquire → 2300 F1805-12030 BOLT,W/WASHER, B/W 2 Enquire → 2400 05978-12095 BOLT 2 Enquire → 2500 F2515-12000 WASHER,SPRING 2 Enquire →
P3751-400 OIL FILTER 26 parts
Ref Part No. Name Qty 0300 F2515-12000 WASHER,SPRING 8 Enquire → 0400 F2500-12000 WASHER,PLAIN 7 Enquire → 0700 05507-20400 O-RING 4 Enquire → 0800 05507-10180 O-RING 2 Enquire → 1900 37540-48400 BRACKET KIT,OIL FILTER 1 Enquire → 2000 37540-28700 FILTER ASSY,OIL 1 Enquire → 2000010 * BRACKET ASSY 1 Enquire → 2000020 37540-21100 ELEMENT,OIL 2 Enquire → 2000030 37540-12100 CARTRIDGE,BY-PASS 1 Enquire → 2000040 37140-01300 COCK 1 Enquire → 2000050 36240-05300 COVER 1 Enquire → 2000060 36240-05400 COVER 1 Enquire → 2000070 36240-15600 GASKET 1 Enquire → 2000080 05507-10160 O-RING 2 Enquire → 2000090 36240-05800 PIN 3 Enquire → 2000100 F1035-08025 BOLT 6 Enquire → 2000110 F2515-08000 WASHER,SPRING 6 Enquire → 2000120 F2500-08000 WASHER,PLAIN 6 Enquire → 2000130 F5005-26001 PLUG,TAPERED 1 Enquire → 2000140 F5005-21001 PLUG,TAPERED 4 Enquire → 2000150 37540-11300 ALARM,OIL FILTER 1 Enquire → 2000160 F4202-24000 GASKET 1 Enquire → 2200 37536-05802 ADAPTER,OIL FILTER 1 Enquire → 2300 F1035-12040 BOLT 5 Enquire → 2350 05978-12150 BOLT 3 Enquire → 2450 F1035-12065 BOLT 5 Enquire →
P3751-420 OIL FILLER 4 parts
P3751-425 OIL LEVEL GAGE 9 parts
P3751-430 BREATHER 16 parts
Ref Part No. Name Qty 0600 37543-03300 HOSE,RUBBER 1 Enquire → 0700 05317-50701 CLAMP 4 Enquire → 0800 37543-08600 PIPE,BREATHER 1 Enquire → 0850 35B36-02900 GASKET,OIL 1 Enquire → 0900 F1805-12035 BOLT,W/WASHER, B/W 2 Enquire → 1000 05507-20600 O-RING 1 Enquire → 1100 F1805-10025 BOLT,W/WASHER, B/W 2 Enquire → 2300 47500-51301 PIPE,BREATHER 1 Enquire → 2400 37543-18500 BREATHER,UPPER 1 Enquire → 2500 04826-28050 PACKING 2 Enquire → 2600 05507-10420 O-RING 1 Enquire → 2700 F1805-10025 BOLT,W/WASHER, B/W 4 Enquire → 2900 F1825-10020 BOLT,W/WASHER, B/W 1 Enquire → 3000 32542-11300 ELEMENT,BREATHER 1 Enquire → 3200 F4010-50010 HOSE,RUBBER 1 Enquire → 3300 05317-50701 CLAMP 2 Enquire →
P3751-450 WATER PUMP 49 parts
Ref Part No. Name Qty 0150 37545-10050 PUMP ASSY,WATER 1 Enquire → 0150010 * CASE,WATER PUMP 1 Enquire → 0150020 37545-00200 COVER,WATER PUMP 1 Enquire → 0150030 F3153-17000 O-RING 1 Enquire → 0150040 37545-30400 SHAFT,WATER PUMP 1 Enquire → 0150050 37545-00500 IMPELLER 1 Enquire → 0150060 37545-30600 SEAL,UNIT 1 Enquire → 0150070 37545-00700 PULLEY,WATER PUMP 1 Enquire → 0150080 37545-20800 SPACER 1 Enquire → 0150090 37545-01300 SEAL,OIL 1 Enquire → 0150100 37545-01400 SEAL,OIL 1 Enquire → 0150110 F8012-06308 BEARING,BALL 1 Enquire → 0150120 F8008-06208 BEARING,BALL 1 Enquire → 0150130 37545-00300 RING,SNAP 1 Enquire → 0150140 F2320-24000 NUT,JAM 1 Enquire → 0150150 37545-01501 WASHER 1 Enquire → 0150160 37545-01600 KEY,WOODRUFF 1 Enquire → 0150170 F3202-09000 RING,SNAP 1 Enquire → 0150180 F3156-04000 O-RING 1 Enquire → 0150190 34A35-00900 PLUG 1 Enquire → 0150200 37745-00901 PIPE 1 Enquire → 0160 F5006-10000 PLUG,TAPERED 1 Enquire → 0200 F3153-09500 O-RING 1 Enquire → 0300 05507-10150 O-RING 1 Enquire → 0400 05507-20250 O-RING 1 Enquire → 0500 F1805-12030 BOLT,W/WASHER, B/W 3 Enquire → 0510 F1805-12050 BOLT,W/WASHER, B/W 2 Enquire → 0600 37549-06590 V-BELT,RAW EDGE, W=22.8 L=1535 1 Enquire → 0700 37545-28010 PULLEY ASSY,TENSION 1 Enquire → 0700010 F1035-12025 BOLT 1 Enquire → 0700020 F2515-12000 WASHER,SPRING 1 Enquire → 0700030 35A45-12100 PLATE,THRUST 1 Enquire → 0700040 35A45-11302 PULLEY,TENSION 1 Enquire → 0700050 35A45-01501 SPACER 1 Enquire → 0700060 37545-18300 BRACKET,TENSION 1 Enquire → 0700070 35A45-12200 SPACER 1 Enquire → 0700080 F3202-05200 RING,SNAP 1 Enquire → 0700090 35A45-01401 BEARING,BALL 2 Enquire → 0720 37545-08201 PLATE,TENSION 1 Enquire → 0740 37545-18400 PLATE,SLIDE 1 Enquire → 0760 37545-18600 BOLT,TENSION 1 Enquire → 0780 F2305-12000 NUT,LOCK 1 Enquire → 0800 F1805-10030 BOLT,W/WASHER, B/W 2 Enquire → 0820 F1035-14030 BOLT 2 Enquire → 0830 F2515-14000 WASHER,SPRING 2 Enquire → 1000 37545-02900 COCK,WATER DRAIN 1 Enquire → 1010 34407-02700 CONNECTOR 1 Enquire → 1100 F4300-00800 CLAMP,HOSE 1 Enquire → 1200 F4002-05100 TUBE,SOFT VINYL 1 Enquire →
P3751-461 COOLING SYSTEM 41 parts
Ref Part No. Name Qty 0300 38C46-01100 CONNECTOR 6 Enquire → 0400 05505-31065 O-RING 12 Enquire → 0410 05505-57060 O-RING 1 Enquire → 0550 F1805-10025 BOLT,W/WASHER, B/W 2 Enquire → 0600 37546-11300 RING,SNAP 6 Enquire → 1350 37546-01600 LABEL,CAUTION 1 Enquire → 1900 32546-46800 GASKET,SEA WATER 1 Enquire → 1950 F3153-06000 O-RING 1 Enquire → 2400 04827-82100 PLUG,TAPERED 1 Enquire → 3210 47500-60400 COVER 1 Enquire → 3215 F5006-10000 PLUG,TAPERED 1 Enquire → 3300 37546-19800 PACKING 1 Enquire → 3400 F1805-12030 BOLT,W/WASHER, B/W 4 Enquire → 4650 45R46-10200 PIPE,WATER INLET 1 Enquire → 4700 45R46-10100 PIPE,WATER INLET 1 Enquire → 4705 04826-40040 COUPLING 1 Enquire → 4750 37532-12700 PACKING 1 Enquire → 4755 F1805-10025 BOLT,W/WASHER, B/W 4 Enquire → 4760 37546-22301 PIPE,WATER OUTLET 1 Enquire → 4770 37546-22401 PIPE,WATER OUTLET 1 Enquire → 4780 45352-74601 PACKING 1 Enquire → 4790 F1805-12025 BOLT,W/WASHER, B/W 4 Enquire → 4815 04826-40040 COUPLING 1 Enquire → 4820 32546-20300 PACKING 1 Enquire → 4900 45346-72802 PIPE,WATER 1 Enquire → 4950 45346-72603 PIPE,WATER 1 Enquire → 5000 04826-40065 COUPLING 1 Enquire → 5050 F3153-10000 O-RING 1 Enquire → 5150 F2005-12035 BOLT,W/WASHER, B/W 4 Enquire → 5170 F1805-12035 BOLT,W/WASHER, B/W 2 Enquire → 5200 F1035-12055 BOLT 1 Enquire → 5250 F2515-12000 WASHER,SPRING 1 Enquire → 5320 45346-74901 PIPE,WATER 1 Enquire → 5350 45352-74601 PACKING 2 Enquire → 5360 37546-05300 PLATE,REDUCER 1 Enquire → 5400 F2005-12030 BOLT,W/WASHER, B/W 4 Enquire → 5600 32545-22900 COCK,DRAIN 1 Enquire → 5650 F4002-05100 TUBE,SOFT VINYL 1 Enquire → 5700 F4300-00800 CLAMP,HOSE 1 Enquire → 5800 05317-40800 CLIP 1 Enquire → 6100 45352-74601 PACKING 1 Enquire →
P3751-510 SEA WATER COOLING 48 parts
Ref Part No. Name Qty 0010 04826-00065 FLANGE 1 Enquire → 0020 04826-00065 FLANGE 1 Enquire → 0030 04826-28065 PACKING 1 Enquire → 0040 04826-28065 PACKING 1 Enquire → 0050 04826-41050 COUPLING 1 Enquire → 0060 05946-02001 WASHER,SEALING 1 Enquire → 0070 05979-10120 BOLT 4 Enquire → 0080 07533-10000 WASHER,INSULATION 4 Enquire → 0090 07606-10045 BOLT,INSULATION 4 Enquire → 0100 42732-04300 COCK,DRAIN 1 Enquire → 0110 37551-08601 PLATE 2 Enquire → 0120 37551-18700 FLANGE 1 Enquire → 0130 42732-04300 PLUG,TAPERED 1 Enquire → 0140 42783-02100 PACKING 1 Enquire → 0150 42783-02100 PACKING 3 Enquire → 0160 42783-08400 COCK,DRAIN 1 Enquire → 0170 42790-58513 ZINC,ELECTRODE 1 Enquire → 0180 45346-73401 PIPE,SEA WATER 1 Enquire → 0190 45352-76400 PACKING 1 Enquire → 0200 45352-76400 PACKING 3 Enquire → 0210 45352-77400 FLANGE 1 Enquire → 0220 45352-77700 PIPE,SEA WATER 1 Enquire → 0230 45R51-12500 PIPE,SEA WATER 1 Enquire → 0240 45R51-50100 PIPE,SEA WATER 1 Enquire → 0250 45R51-50200 PIPE,SEA WATER 1 Enquire → 0261 45R51-51100 BRACKET,PIPE 1 Enquire → 0262 F1035-16060 BOLT 2 Enquire → 0263 F2515-16000 WASHER,SPRING 2 Enquire → 0270 F1035-12045 BOLT 2 Enquire → 0280 F1035-12045 BOLT 4 Enquire → 0290 F1035-12050 BOLT 2 Enquire → 0300 F1155-12120 BOLT 4 Enquire → 0310 F1805-12025 BOLT,W/WASHER, B/W 2 Enquire → 0320 F2005-10030 BOLT,W/WASHER, B/W 4 Enquire → 0330 F2005-10040 BOLT,W/WASHER, B/W 4 Enquire → 0340 F2005-12035 BOLT,W/WASHER, B/W 4 Enquire → 0350 F2300-12000 NUT 4 Enquire → 0360 F2300-12000 NUT 4 Enquire → 0370 F2500-10000 WASHER,PLAIN 4 Enquire → 0380 F2515-10000 WASHER,SPRING 4 Enquire → 0390 F2515-10000 WASHER,SPRING 4 Enquire → 0400 F2515-12000 WASHER,SPRING 4 Enquire → 0410 F2515-12000 WASHER,SPRING 4 Enquire → 0420 F2515-12000 WASHER,SPRING 4 Enquire → 0430 F3153-07000 O-RING 1 Enquire → 0440 F3153-09000 O-RING 1 Enquire → 0460 F4002-10100 TUBE,SOFT VINYL 1 Enquire → 0470 F4300-01000 CLAMP,HOSE 1 Enquire →
P3751-520-01 HEAT EXCHANGER 19 parts
Ref Part No. Name Qty 0101 45967-68500 PACKING,LEVEL GAGE 4 Enquire → 0200 45352-76800 BRACKET 1 Enquire → 0300 F1805-12035 BOLT,W/WASHER, B/W 7 Enquire → 0310 F1035-12045 BOLT 1 Enquire → 0320 F2515-12000 WASHER,SPRING 1 Enquire → 0500 F2005-12030 BOLT,W/WASHER, B/W 6 Enquire → 0600 37552-01101 STAY,L.H. 1 Enquire → 0700 F1155-10075 BOLT 2 Enquire → 0900 42722-15100 SPACER 2 Enquire → 2200 37552-01200 PIPE,DRAIN 1 Enquire → 2300 30007-05500 CLAMP 1 Enquire → 3500 F2515-10000 WASHER,SPRING 2 Enquire → 3700 33546-06900 COVER 1 Enquire → 3800 32546-46800 GASKET 1 Enquire → 3900 F2005-12025 BOLT,W/WASHER, B/W 2 Enquire → 4600 F1805-12030 BOLT,W/WASHER, B/W 3 Enquire → 5000 45352-79900 HANGER,FRONT 1 Enquire → 5010 F1035-16030 BOLT 3 Enquire → 5020 F2515-16000 WASHER,SPRING 3 Enquire →
P3751-520-02 HEAT EXCHANGER (ASSY) 50 parts
Ref Part No. Name Qty 0100 45352-99004 EXCHANGER ASSY,HEAT 1 Enquire → 0100010 45352-78100 TANK,EXPANSION 1 Enquire → 0100020 45352-78202 COVER,R.H. 1 Enquire → 0100030 45352-78302 COVER,L.H. 1 Enquire → 0100040 45352-96302 ELEMENT 1 Enquire → 0100050 45352-88400 COVER,THERMOSTAT 1 Enquire → 0100060 45352-79300 PIPE 1 Enquire → 0100070 37546-50700 THERMOSTAT 2 Enquire → 0100080 37546-00800 SEAL,THERMOSTAT 2 Enquire → 0100090 F3153-20000 O-RING 1 Enquire → 0100100 F3153-08000 O-RING 4 Enquire → 0100110 * ZINC ASSY 2 Enquire → 0100111 45352-79200 ZINC 2 Enquire → 0100112 45352-79111 FLANGE 2 Enquire → 0100113 45352-79112 PACKING 2 Enquire → 0100114 F2300-12000 NUT 2 Enquire → 0100115 F2515-12000 WASHER,SPRING 2 Enquire → 0100120 45352-74701 PACKING 2 Enquire → 0100130 45352-74800 PACKING 1 Enquire → 0100140 45352-75600 FLANGE 1 Enquire → 0100150 45352-74601 PACKING 1 Enquire → 0100160 45352-74900 PACKING 2 Enquire → 0100170 32546-39800 GASKET 2 Enquire → 0100180 32546-17700 PACKING 1 Enquire → 0100190 45450-01401 NECK,FILLER 1 Enquire → 0100200 46636-22070 CAP,PRESSURE 1 Enquire → 0100210 37552-08700 COVER 1 Enquire → 0100220 F4002-08200 TUBE,SOFT VINYL 1 Enquire → 0100230 F4300-01200 CLAMP,HOSE 1 Enquire → 0100240 32336-09501 CLAMP 1 Enquire → 0100250 45967-68512 GAGE,LEVEL 1 Enquire → 0100260 33407-06100 COCK 1 Enquire → 0100270 42790-58513 ZINC,ELECTRODE 2 Enquire → 0100280 45146-72800 COVER 1 Enquire → 0100290 F5000-20000 PLUG,DRAIN 3 Enquire → 0100320 05946-02001 WASHER,SEALING 5 Enquire → 0100330 05979-10150 BOLT 2 Enquire → 0100340 F1155-10065 BOLT 6 Enquire → 0100350 F1155-10050 BOLT 4 Enquire → 0100360 05979-10130 BOLT 2 Enquire → 0100370 F1155-10030 BOLT 4 Enquire → 0100380 F1155-10040 BOLT 6 Enquire → 0100390 F1155-12030 BOLT 8 Enquire → 0100400 05979-10115 BOLT 6 Enquire → 0100430 F2005-12025 BOLT,W/WASHER, B/W 3 Enquire → 0100440 F1805-08016 BOLT,W/WASHER, B/W 8 Enquire → 0100450 F1155-12030 BOLT 4 Enquire → 0100460 F2515-10000 WASHER,SPRING 26 Enquire → 0100470 F2515-12000 WASHER,SPRING 16 Enquire → 0100480 42732-03600 PLUG 2 Enquire →
P3751-530 SEA WATER PUMP 31 parts
Ref Part No. Name Qty 0100 37553-30100 PUMP ASSY,SEA WATER 1 Enquire → 0100010 45B53-10111 BODY 1 Enquire → 0100020 45B53-10112 CASE,BEARING 1 Enquire → 0100030 45B53-10113 SHAFT 1 Enquire → 0100040 45B53-10114 PLATE,WEAR 1 Enquire → 0100050 45B53-10115 COVER 1 Enquire → 0100060 45B53-10300 HOUSING 1 Enquire → 0100070 45B53-10201 IMPELLER 1 Enquire → 0100080 45B53-20118 SEAL UNIT,MECANICAL 1 Enquire → 0100090 45B53-10119 SEAL,OIL 1 Enquire → 0100100 45B53-10121 O-RING 1 Enquire → 0100110 45B53-10122 BEARING 1 Enquire → 0100120 45B53-10123 BEARING 1 Enquire → 0100130 45B53-10124 CLIP 1 Enquire → 0100140 45B53-10125 O-RING 1 Enquire → 0100150 45B53-10126 O-RING 1 Enquire → 0100160 45B53-10127 O-RING 2 Enquire → 0100170 45B53-10128 BOLT 8 Enquire → 0100180 45B53-10129 BOLT 8 Enquire → 0100190 45B53-10131 WASHER,SPRING 16 Enquire → 0100200 45B53-10132 NUT 1 Enquire → 0100210 45B53-10133 PIPE,DRAIN 1 Enquire → 0100220 45B53-10134 KEY 1 Enquire → 0100230 45B53-10135 O-RING 1 Enquire → 0105 42783-00144 WASHER,LOCK 1 Enquire → 0210 45R53-10100 GEAR,SEA WATER PUMP, Z=24 1 Enquire → 0310 45R53-21201 PLATE 1 Enquire → 0400 05507-21250 O-RING 1 Enquire → 0500 F1805-10030 BOLT,W/WASHER, B/W 7 Enquire → 0600 F1035-16110 BOLT 4 Enquire → 0700 F4002-10100 TUBE,SOFT VINYL 1 Enquire →
P3751-550 AIR COOLER 25 parts
Ref Part No. Name Qty 0305 05978-12290 BOLT 3 Enquire → 0315 05978-12165 BOLT 23 Enquire → 0340 33311-01600 WASHER 26 Enquire → 2000 37555-50080 COOLER ASSY,AIR 1 Enquire → 2000010 37555-03100 ELEMENT 1 Enquire → 2000020 37555-23200 COVER,AIR COOLER 1 Enquire → 2000030 37555-03302 CASE,AIR COOLER 1 Enquire → 2000040 37555-33400 GASKET 2 Enquire → 2000050 37555-03500 PLATE 2 Enquire → 2000060 37555-15700 CONNECTOR 2 Enquire → 2000070 05507-20650 O-RING 4 Enquire → 2000080 05507-20900 O-RING 2 Enquire → 2000090 F2005-10025 BOLT,W/WASHER, B/W 8 Enquire → 2000100 F1210-08035 BOLT 10 Enquire → 2000110 F2500-10000 WASHER,PLAIN 8 Enquire → 2100 37555-28500 GASKET 1 Enquire → 2400 45R30-11300 PLATE 1 Enquire → 2450 37555-10600 GASKET,AIR 1 Enquire → 2500 F1805-10025 BOLT,W/WASHER, B/W 2 Enquire → 2650 F5000-10000 PLUG,DRAIN 1 Enquire → 2660 F4202-10000 GASKET 1 Enquire → 2700 37555-28300 COVER,AIR COOLER, DOUBLE INJECTION 1 Enquire → 2750 45R55-50100 COVER,AIR COOLER, SINGLE INJECTION 1 Enquire → 2900 F1805-10045 BOLT,W/WASHER, B/W 8 Enquire → 3000 F2500-10000 WASHER,PLAIN 8 Enquire →
P3751-610 INJECTION PUMP BRACKET 32 parts
Ref Part No. Name Qty 0360 48A10-14012 PUMP ASSY,INJECTION 1 Enquire → 0400 37561-21101 BRACKET,INJECTION PUMP 1 Enquire → 0450 05507-10140 O-RING 1 Enquire → 0500 F1035-12035 BOLT 3 Enquire → 0550 05978-12150 BOLT 2 Enquire → 0600 37525-07901 WASHER 5 Enquire → 0800 F1035-12110 BOLT 4 Enquire → 0850 37561-01800 PIN,DOWEL 2 Enquire → 0900 37525-07901 WASHER 4 Enquire → 1000 37561-10701 STAY,INJECTION PUMP 1 Enquire → 1010 F1035-12025 BOLT 2 Enquire → 1020 F2515-12000 WASHER,SPRING 2 Enquire → 1030 F1035-14030 BOLT 2 Enquire → 1040 F2515-14000 WASHER,SPRING 2 Enquire → 1315 37561-09502 COVER,COUPLING 1 Enquire → 1320 37561-53200 BRACKET,COUPLING COVER 1 Enquire → 1330 F1825-08016 BOLT,W/WASHER, B/W 3 Enquire → 1340 F1035-12075 BOLT 1 Enquire → 1350 F2515-12000 WASHER,SPRING 1 Enquire → 1400 48230-05200 BOLT,EYE 1 Enquire → 1450 05946-01401 WASHER,SEALING 2 Enquire → 1500 31262-51901 COCK,AIR VENT 1 Enquire → 4500 37561-11901 SPRING,RETURN 1 Enquire → 4510 F2500-10000 WASHER,PLAIN 1 Enquire → 4520 F2515-10000 WASHER,SPRING 1 Enquire → 4530 F2445-10000 NUT,SELF LOCKING 1 Enquire → 4540 37561-42801 CASE,SPRING 1 Enquire → 4550 05507-10360 O-RING 1 Enquire → 4560 F1805-08020 BOLT,W/WASHER, B/W 2 Enquire → 4570 F2325-08000 NUT,JAM 2 Enquire → 4580 05946-02701 WASHER,SEALING 1 Enquire → 4595 37561-09901 CAP,RACK SET 1 Enquire →
P48A1-110 PUMP ASSY (PLUNGER BARREL) 44 parts
Ref Part No. Name Qty 0400 48A11-04001 PLUNGER ASSY 6 Enquire → 0400010 * BARREL 6 Enquire → 0400020 * PLUNGER 6 Enquire → 0400030 49168-18800 PIN,KNOCK 6 Enquire → 1100 48202-12400 O-RING 18 Enquire → 1300 48A11-02101 PINION, R5 6 Enquire → 1400 48202-21202 SEAT,SPRING, UPPER 6 Enquire → 1500 48202-21302 SEAT,SPRING, LOWER 6 Enquire → 1600 48202-11700 SPRING,PLUNGER 6 Enquire → 1700 48202-02601 BOLT,BARREL 6 Enquire → 1800 48202-07601 BOLT,BARREL 6 Enquire → 1900 48202-22800 WASHER,BARREL 12 Enquire → 2000 * SHIM SET,BARREL 6 Enquire → 2000010 48270-05100 SHIM,BARREL, T=0.40 AR Enquire → 2000020 48270-05200 SHIM,BARREL, T=0.45 AR Enquire → 2000030 48270-05300 SHIM,BARREL, T=0.50 AR Enquire → 2000040 48270-05400 SHIM,BARREL, T=0.55 AR Enquire → 2000050 48270-05500 SHIM,BARREL, T=0.60 AR Enquire → 2000060 48270-05600 SHIM,BARREL, T=0.65 AR Enquire → 2000070 48270-05700 SHIM,BARREL, T=0.70 AR Enquire → 2000080 48270-05800 SHIM,BARREL, T=0.75 AR Enquire → 2000090 48270-05900 SHIM,BARREL, T=0.80 AR Enquire → 2000100 48270-06100 SHIM,BARREL, T=0.85 AR Enquire → 2000110 48270-06200 SHIM,BARREL, T=0.90 AR Enquire → 2000120 48270-06300 SHIM,BARREL, T=0.95 AR Enquire → 2000130 48270-06350 SHIM,BARREL, T=0.97 AR Enquire → 2000140 48270-06400 SHIM,BARREL, T=1.00 AR Enquire → 2000150 48270-06500 SHIM,BARREL, T=1.05 AR Enquire → 2000160 48270-06600 SHIM,BARREL, T=1.10 AR Enquire → 2000170 48270-06700 SHIM,BARREL, T=1.15 AR Enquire → 2000180 48270-06800 SHIM,BARREL, T=1.20 AR Enquire → 2000190 48270-06900 SHIM,BARREL, T=1.25 AR Enquire → 2000200 48270-07100 SHIM,BARREL, T=1.30 AR Enquire → 2000210 48270-07200 SHIM,BARREL, T=1.35 AR Enquire → 2000220 48270-07300 SHIM,BARREL, T=1.40 AR Enquire → 2000230 48270-07400 SHIM,BARREL, T=1.45 AR Enquire → 2000240 48270-07500 SHIM,BARREL, T=1.50 AR Enquire → 2000250 48270-07600 SHIM,BARREL, T=1.55 AR Enquire → 2000260 48270-07700 SHIM,BARREL, T=1.60 AR Enquire → 2000270 48270-07800 SHIM,BARREL, T=1.65 AR Enquire → 2000280 48270-07900 SHIM,BARREL, T=1.70 AR Enquire → 2000290 48270-08100 SHIM,BARREL, T=1.75 AR Enquire → 2100 48202-05800 WIRE 1 Enquire → 2200 48202-07700 SEAL 1 Enquire →
P48A1-120 PUMP ASSY (RACK CONTROL) 6 parts
P48A1-130 PUMP ASSY (PUMP CASE) 18 parts
Ref Part No. Name Qty 0050 48A13-10100 CASE,PUMP 1 Enquire → 1100 48202-02901 PIN 7 Enquire → 1200 04826-21000 CAP,SEALING 7 Enquire → 1300 48202-42501 BUSH,RACK 2 Enquire → 1500 48202-05500 BOLT,EYE 2 Enquire → 1510 05946-00801 WASHER,SEALING 2 Enquire → 4000 * PLATE,NAME 1 Enquire → 4010 00665-02048 RIVET,SCREW 2 Enquire → 4100 48202-54001 VALVE ASSY,CHECK 1 Enquire → 4100010 * SCREW 1 Enquire → 4100020 05634-01200 NUT,SELF LOCKING 1 Enquire → 4100030 * BODY,VALVE 1 Enquire → 4100040 05507-10060 O-RING 1 Enquire → 4100050 * SPRING,VALVE 1 Enquire → 4100060 F8000-08000 STEEL BALL,BEARING 1 Enquire → 4110 05946-01401 WASHER,SEALING 2 Enquire → 4200 F5000-12000 PLUG,DRAIN 1 Enquire → 4210 05946-01201 WASHER,SEALING 1 Enquire →
P48A1-140 PUMP ASSY (CAMSHAFT) 19 parts
Ref Part No. Name Qty 0300 48210-20201 CAMSHAFT 1 Enquire → 0900 F2870-07025 KEY,WOODRUFF 1 Enquire → 1000 F8143-32207 BEARING,TAPERED ROLLER 2 Enquire → 1100 48202-22203 COVER,REAR 1 Enquire → 1110 05507-20800 O-RING 1 Enquire → 1120 48202-07100 SEAL,OIL 1 Enquire → 1130 F1010-08025 BOLT,FLANGE 4 Enquire → 1200 48202-14100 SHIM,CASE, T=0.50 AR Enquire → 1210 48202-14200 SHIM,CASE, T=0.10 AR Enquire → 1220 48202-14300 SHIM,CASE, T=0.15 AR Enquire → 1230 48202-14400 SHIM,CASE, T=0.30 AR Enquire → 1300 48210-35603 COVER,FRONT 1 Enquire → 1310 05507-20800 O-RING 1 Enquire → 1330 F1010-08025 BOLT,FLANGE 4 Enquire → 1400 48202-02300 BEARING,CENTER 1 Enquire → 1410 F1010-08050 BOLT,FLANGE 2 Enquire → 1420 05507-10080 O-RING 2 Enquire → 1500 F2325-24000 NUT,JAM 1 Enquire → 1600 32507-01400 WASHER 1 Enquire →
P48A1-150 PUMP ASSY (TAPPET) 5 parts
P48A1-160 PUMP ASSY (CPV) 7 parts
P48A1-170 PUMP ASSY (6B/22B COUPLING) 15 parts
Ref Part No. Name Qty 0100 48251-00101 FLYWHEEL 1 Enquire → 0250 48251-16301 COUPLING,CROSS 1 Enquire → 0400 48251-30400 WASHER,COUPLING 8 Enquire → 0500 48251-30500 BUSHING 8 Enquire → 0600 48251-00600 WASHER,COUPLING WIDE 2 Enquire → 0700 48251-20700 NUT,FLANGE 2 Enquire → 0800 48251-10801 BOLT,SHORT 6 Enquire → 0900 48251-10901 BOLT,LONG 2 Enquire → 1000 48A17-08100 WASHER,COUPLING 1 Enquire → 1100 F1035-14085 BOLT 1 Enquire → 1400 48251-11400 PLATE,LAMINATE, T=0.8 14 Enquire → 2120 48C17-11201 COUPLING, D48-M14-6B/22B 1 Enquire → 3420 48C17-31018 COUPLING KIT 1 Enquire → 4421 48C17-31010 COUPLING ASSY 1 Enquire → 5000 * LAMINATE PLATE KIT 2 Enquire →
P48A1-180 PUMP ASSY (DEFLECTOR BOLT) 2 parts
Ref Part No. Name Qty 0100 48A13-01102 BOLT,DEFLECTOR 12 Enquire → 1000 05946-01201 WASHER,SEALING 12 Enquire →
P48A1-190 PUMP ASSY (FEED PUMP) 23 parts
Ref Part No. Name Qty 0100 04245-00120 PUMP,FEED 1 Enquire → 0100001 15200-21720 HOUSING 1 Enquire → 0100002 15210-01120 PISTON 1 Enquire → 0100003 15210-40100 SPRING,PISTON 1 Enquire → 0100004 15210-50400 PLUG 1 Enquire → 0100005 15211-11920 TAPPET ASSY 1 Enquire → 0100006 15211-20100 ROLLER 1 Enquire → 0100007 15211-30700 PIN 1 Enquire → 0100008 15211-40400 GUIDE 2 Enquire → 0100009 15211-50200 VALVE 4 Enquire → 0100010 15211-60200 SPRING 4 Enquire → 0100011 15211-70100 PLUG 3 Enquire → 0100012 15212-10200 RING,SNAP 1 Enquire → 0100013 * PUMP,PRIMING 1 Enquire → 0100014 15230-04020 BOLT,EYE 1 Enquire → 0100015 02973-14570 BOLT,EYE 1 Enquire → 0100016 02934-14130 GASKET 5 Enquire → 0100017 15231-01300 ADAPTER 2 Enquire → 0101 04245-01120 PUMP KIT,FEED 1 Enquire → 0105 48A19-00100 PUMP,FEED 1 Enquire → 0200 05507-20350 O-RING 1 Enquire → 0300 F1010-06016 BOLT,FLANGE, B/W 3 Enquire → 0500 05946-01401 WASHER,SEALING 2 Enquire →
P48A1-200 PUMP ASSY (EYE BOLT) 2 parts
Ref Part No. Name Qty 0100 F4610-14000 BOLT,EYE 1 Enquire → 1000 05946-01401 WASHER,SEALING 2 Enquire →
P48A1-230 PUMP ASSY (POINTER) 2 parts
P48A1-950 PUMP ASSY (PLUNGER BLOCK) 2 parts
Ref Part No. Name Qty 0400 48A95-04002 BLOCK ASSY,PLUNGER 6 Enquire → 1100 48291-00301 HOLDER,PLUNGER 6 Enquire →
P3751-612-01 INJECTION PIPE (SINGLE INJ. PIPE SPEC.) 44 parts
Ref Part No. Name Qty 0150 37561-01602 GLAND,NOZZLE 6 Enquire → 0160 F2305-14000 NUT 6 Enquire → 0170 33561-14500 WASHER,NOZZLE GLAND 6 Enquire → 0200 05507-10420 O-RING 6 Enquire → 0210 05507-10340 O-RING 6 Enquire → 0220 05507-10260 O-RING 6 Enquire → 0300 37561-16800 GASKET,NOZZLE 6 Enquire → 0350 37561-23500 COVER 12 Enquire → 0360 37561-13600 HOLDER 12 Enquire → 0370 37861-04400 HOLDER 12 Enquire → 0400 37562-47100 PIPE,INJECTION, NO.1 1 Enquire → 0500 37562-47200 PIPE,INJECTION, NO.2 1 Enquire → 0600 37562-47300 PIPE,INJECTION, NO.3 1 Enquire → 0700 37562-47400 PIPE,INJECTION, NO.4 1 Enquire → 0800 37562-47500 PIPE,INJECTION, NO.5 1 Enquire → 0900 37562-47600 PIPE,INJECTION, NO.6 1 Enquire → 1500 37561-08800 BUSHING,INJECTION PIPE 6 Enquire → 1510 05318-00300 BAND,CLIP 6 Enquire → 1610 37562-12800 CLAMP 1 Enquire → 1620 37562-12812 SEAT,PIPE 1 Enquire → 1630 37562-08100 BRACKET,INJECTION PUMP 1 Enquire → 1640 F1035-12035 BOLT 2 Enquire → 1650 F2515-12000 WASHER,SPRING 2 Enquire → 1800 F1805-08035 BOLT,W/WASHER, B/W 7 Enquire → 2010 37562-13301 SEAT,PIPE 8 Enquire → 2103 37562-15902 PLATE,CLAMP 13 Enquire → 2110 37562-13101 SEAT,PIPE 14 Enquire → 2130 37562-13401 SEAT,PIPE 7 Enquire → 2150 37761-03602 PLATE,CLAMP 3 Enquire → 2280 F1035-10090 BOLT 6 Enquire → 2290 F1805-10050 BOLT,W/WASHER, B/W 4 Enquire → 2300 F1805-10080 BOLT,W/WASHER, B/W 4 Enquire → 2310 F1805-10055 BOLT,W/WASHER, B/W 4 Enquire → 2350 F2515-10000 WASHER,SPRING 12 Enquire → 2360 35A60-04100 CLAMP 3 Enquire → 2370 35A60-04200 CLAMP 3 Enquire → 2380 F1805-06030 BOLT,W/WASHER, B/W 3 Enquire → 2400 MM430-70301 CLAMP 4 Enquire → 2450 F2515-06000 WASHER,SPRING 2 Enquire → 2500 F2300-06000 NUT 2 Enquire → 2600 F1035-06025 BOLT 2 Enquire → 2610 F1035-10070 BOLT 4 Enquire → 2620 F1035-10045 BOLT 2 Enquire → 2640 F2300-10000 NUT,LOCK 6 Enquire →
P3751-612-02 INJECTION PIPE (DOUBLE INJ. PIPE SPEC.) 41 parts
Ref Part No. Name Qty 0150 37561-01602 GLAND,NOZZLE 6 Enquire → 0160 F2305-14000 NUT 6 Enquire → 0170 33561-14500 WASHER,NOZZLE GLAND 6 Enquire → 0200 05507-10420 O-RING 6 Enquire → 0210 05507-10340 O-RING 6 Enquire → 0220 05507-10260 O-RING 6 Enquire → 0300 37561-16800 GASKET,NOZZLE 6 Enquire → 0355 37561-19600 COVER 6 Enquire → 0365 37561-09700 HOLDER 6 Enquire → 0370 37861-04400 HOLDER 6 Enquire → 0380 37861-04500 HOLDER,CUT 6 Enquire → 1500 37561-08800 BUSHING,INJECTION PIPE 6 Enquire → 1510 05318-00300 BAND,CLIP 6 Enquire → 1600 37561-04400 CLAMP 2 Enquire → 1800 F1805-08035 BOLT,W/WASHER, B/W 7 Enquire → 1900 F2515-08000 WASHER,SPRING 7 Enquire → 1950 F2300-08000 NUT 7 Enquire → 2100 37562-23600 SEAT,PIPE 9 Enquire → 2103 37562-15902 PLATE,CLAMP 7 Enquire → 2120 37562-13500 SEAT,PIPE 7 Enquire → 2140 37761-15401 SEAT,PIPE 5 Enquire → 2150 37761-03602 PLATE,CLAMP 3 Enquire → 2280 F1035-10090 BOLT 6 Enquire → 2290 F1805-10050 BOLT,W/WASHER, B/W 4 Enquire → 2300 F1805-10080 BOLT,W/WASHER, B/W 4 Enquire → 2310 F1805-10055 BOLT,W/WASHER, B/W 4 Enquire → 2350 F2515-10000 WASHER,SPRING 6 Enquire → 4100 37562-67100 PIPE,INJECTION, NO.1 1 Enquire → 4200 37562-67200 PIPE,INJECTION, NO.2 1 Enquire → 4300 37562-67300 PIPE,INJECTION, NO.3 1 Enquire → 4400 37562-67400 PIPE,INJECTION, NO.4 1 Enquire → 4500 37562-67500 PIPE,INJECTION, NO.5 1 Enquire → 4600 37562-67601 PIPE,INJECTION, NO.6 1 Enquire → 5300 37561-03401 CONNECTOR,LEAK 6 Enquire → 5400 37562-04800 O-RING 12 Enquire → 5500 F3200-02500 RING,SNAP 6 Enquire → 5600 05946-00801 WASHER,SEALING 12 Enquire → 5700 37561-20600 PIPE,LEAK OFF 1 Enquire → 5800 30036-03604 BOLT,JOINT 6 Enquire → 5900 F4510-06000 NIPPLE 1 Enquire → 6000 F4521-06300 NUT,UNION 1 Enquire →
P3751-612-03 INJECTION PIPE (NOZZLE ASSY) 17 parts
Ref Part No. Name Qty 0090 37860-06002 NOZZLE ASSY 6 Enquire → 0090010 37560-08400 TIP ASSY,NOZZLE 6 Enquire → 0090020 37561-86100 BODY,NOZZLE HOLDER 6 Enquire → 0090030 37760-03200 PUSHROD,NOZZLE 6 Enquire → 0090040 37561-26300 NUT,RETAINING 6 Enquire → 0090050 37561-26400 SPRING,NOZZLE 6 Enquire → 0090060 37561-46500 SCREW,ADJUSTING 6 Enquire → 0090070 37561-16600 NUT,CAP 6 Enquire → 0090080 37561-56700 CONNECTOR,INLET 6 Enquire → 0090090 33407-03901 SCREW,SET 6 Enquire → 0090100 37561-26900 SPACER,NOZZLE 6 Enquire → 0090110 05946-01401 WASHER,SEALING 6 Enquire → 0090120 37561-09300 SEAT,SPRING 6 Enquire → 0090130 F8001-30014 ROLLER,BEARING 12 Enquire → 0090140 F8001-40014 ROLLER,BEARING 12 Enquire → 0090150 05946-01001 WASHER,SEALING 6 Enquire → 0090160 37560-37013 NOZZLE HOLDER ASSY 6 Enquire →
P3751-613 LEAK OFF PIPE 18 parts
Ref Part No. Name Qty 0100 37561-04100 PIPE,FUEL LEAK OFF 1 Enquire → 0200 32536-19400 BOLT,EYE 5 Enquire → 0300 34A36-36100 BOLT,EYE 1 Enquire → 0400 05946-01001 WASHER,SEALING 3 Enquire → 0500 05946-01001 WASHER,SEALING 12 Enquire → 1100 37561-23800 PIPE,LEAK 1 Enquire → 1150 F4110-10000 BOLT,EYE 1 Enquire → 1200 37561-34200 PIPE,LEAK 1 Enquire → 1300 37561-24302 PIPE,FUEL LEAK END 1 Enquire → 1320 F5006-17000 PLUG,TAPERED 1 Enquire → 1350 05946-01401 WASHER,SEALING 3 Enquire → 1400 F4540-10000 CONNECTOR 1 Enquire → 1600 F1805-12025 BOLT,W/WASHER, B/W 2 Enquire → 1900 34A42-03300 SPACER 1 Enquire → 1950 F1805-10050 BOLT,W/WASHER, B/W 1 Enquire → 2010 F1035-12060 BOLT 1 Enquire → 2020 F2515-12000 WASHER,SPRING 1 Enquire → 2600 37561-03700 SPACER 1 Enquire →
P3751-620-01 FUEL FILTER 9 parts
Ref Part No. Name Qty 0400 37562-70800 FILTER ASSY,FUEL 1 Enquire → 1000 37562-16500 BRACKET,FUEL FILTER 1 Enquire → 1010 37562-16600 BRACKET,FUEL FILTER 1 Enquire → 1020 F1035-12070 BOLT 2 Enquire → 1030 F2515-12000 WASHER,SPRING 2 Enquire → 1040 F1805-10020 BOLT,W/WASHER, B/W 2 Enquire → 1100 F1805-12025 BOLT,W/WASHER, B/W 4 Enquire → 1200 F1825-10025 BOLT,W/WASHER, B/W 4 Enquire → 9000 32562-00800 LABEL,CAUTION 1 Enquire →
P3751-620-02 FUEL FILTER (ASSY) 14 parts
P3751-621 FUEL FILTER PIPING 14 parts
P3751-630-01 GOVERNOR (DRIVE GEAR) 23 parts
Ref Part No. Name Qty 0200 04251-22001 GOVERNOR ASSY,PSG 1 Enquire → 0210 37763-06100 SPACER 1 Enquire → 0220 05634-00610 NUT,SELF LOCKING 1 Enquire → 0500 37563-13101 CASE,DRIVE 1 Enquire → 0600 04826-22000 CAP,SEALING 2 Enquire → 0700 05507-21450 O-RING 1 Enquire → 0800 F1035-12045 BOLT 4 Enquire → 1000 F2515-12000 WASHER,SPRING 4 Enquire → 1200 37563-13300 GEAR,DRIVE 1 Enquire → 1300 37563-13400 GEAR,IDLER 1 Enquire → 1350 37563-08400 SHAFT,DRIVE 1 Enquire → 1500 37563-03600 SHAFT,IDLER 1 Enquire → 1600 F8006-06205 BEARING,BALL 2 Enquire → 1700 F8006-06204 BEARING,BALL 2 Enquire → 1900 F3200-02500 RING,SNAP 1 Enquire → 2000 F3202-05200 RING,SNAP 1 Enquire → 2100 F3202-04700 RING,SNAP 1 Enquire → 2200 67352-01500 WASHER 1 Enquire → 2300 F1805-08020 BOLT,W/WASHER, B/W 1 Enquire → 2400 F1450-08045 STUD 4 Enquire → 2470 F2515-08000 WASHER,SPRING 4 Enquire → 2500 F2300-08000 NUT 4 Enquire → 2600 37463-31900 PACKING 1 Enquire →
P3751-630-02 GOVERNOR (OIL PIPING) 43 parts
Ref Part No. Name Qty 2800 F4540-06300 CONNECTOR 2 Enquire → 2900 F4540-08000 CONNECTOR 2 Enquire → 2910 35A37-05601 CONNCTOR 1 Enquire → 3020 37536-87200 BRACKET 1 Enquire → 3050 37536-58300 STAY,OIL TANK 1 Enquire → 3055 37536-68101 STAY,OIL TANK 1 Enquire → 3056 F1035-10100 BOLT 1 Enquire → 3057 F2515-10000 WASHER,SPRING 1 Enquire → 3058 F1805-10020 BOLT,W/WASHER, B/W 1 Enquire → 3060 F1035-10030 BOLT 2 Enquire → 3070 F2400-10000 NUT 2 Enquire → 3080 F2515-10000 WASHER,SPRING 3 Enquire → 3085 F1035-10016 BOLT 1 Enquire → 3090 37540-18500 TANK ASSY,OIL FILTER 1 Enquire → 3090020 MH037084 PLUG,AIR 1 Enquire → 3090030 MH035067 GASKET 2 Enquire → 3090040 ME040245 PACKING,COVER 1 Enquire → 3090050 37540-18511 ELEMENT ASSY 1 Enquire → 3090060 ME040249 SEAT 1 Enquire → 3090070 ME040248 SPRING 1 Enquire → 3090080 * CASE ASSY 1 Enquire → 3090100 ME035070 PACKING 1 Enquire → 3115 32565-06900 VALVE,OVER FLLOW 1 Enquire → 3120 05946-01401 WASHER,SEALING 4 Enquire → 3210 37536-77600 PIPE 1 Enquire → 3215 F1805-10016 BOLT,W/WASHER, B/W 1 Enquire → 3220 37536-87700 PIPE 1 Enquire → 3226 35A37-05400 CONNECTOR 1 Enquire → 3227 F4610-10000 BOLT,EYE 1 Enquire → 3228 05946-01001 WASHER,SEALING 2 Enquire → 3246 37536-77800 PIPE,OIL 1 Enquire → 3250 32161-23500 CLAMP 4 Enquire → 3255 32161-23800 SEAT 4 Enquire → 3260 F1035-08030 BOLT 4 Enquire → 3265 F2400-08000 NUT 4 Enquire → 3270 F2515-08000 WASHER,SPRING 4 Enquire → 3390 F5006-13000 PLUG,TAPERED 1 Enquire → 3505 37563-17600 BOLT,EYE 1 Enquire → 3600 37536-58201 STAY 1 Enquire → 4100 37536-27300 PIPE,DRAIN 1 Enquire → 4200 MH020258 CLAMP 1 Enquire → 4300 34A36-05700 CLAMP 1 Enquire → 4400 F1805-06025 BOLT,W/WASHER, B/W 1 Enquire →
P3751-630-03 GOVERNOR (CONTROL LINK) 30 parts
Ref Part No. Name Qty 4500 F1115-08025 BOLT,LOCKING WIRE HOLE 1 Enquire → 4550 F2515-08000 WASHER,SPRING 1 Enquire → 4600 F1805-12025 BOLT,W/WASHER, B/W 1 Enquire → 4610 37563-05500 BOLT 1 Enquire → 4620 F2515-12000 WASHER,SPRING 1 Enquire → 4700 37563-04103 BRACKET,GOVERNOR 1 Enquire → 4800 34A87-17100 GRIP,LEVER STOP 1 Enquire → 4900 45940-30201 PLATE,CAUTION 1 Enquire → 5000 F1805-08020 BOLT,W/WASHER, B/W 1 Enquire → 5100 F2500-08000 WASHER,PLAIN 1 Enquire → 5200 37563-02901 LEVER,GOVERNOR 1 Enquire → 5400 37563-15402 JOINT,BALL MALE 2 Enquire → 5500 32661-28600 CASE,SPRING 1 Enquire → 5600 32661-08700 SPRING 1 Enquire → 5700 32661-18801 CONNECTOR 1 Enquire → 5800 32661-18901 LINK,GOVERNOR 1 Enquire → 5900 35A61-38602 BALL,JOINT 2 Enquire → 6000 F2300-08000 NUT 3 Enquire → 6100 F2445-08000 NUT,SELF LOCKING 3 Enquire → 6160 F2300-08000 NUT 1 Enquire → 6170 F2515-08000 WASHER,SPRING 1 Enquire → 6300 47500-32200 LEVER,RACK CONTROL 1 Enquire → 6400 F8007-06200 BEARING,BALL 2 Enquire → 6500 F3202-03000 RING,SNAP 1 Enquire → 6600 32561-28300 PLATE,END 1 Enquire → 6700 F1805-10040 BOLT,W/WASHER, B/W 1 Enquire → 6800 34A87-07201 SEAL 3 Enquire → 6900 35A61-19900 WIRE,SEAL 3 Enquire → 9801 37411-02300 PLUG,UNF 5/8 2 Enquire → 9802 F5000-18000 PLUG,DRAIN 1 Enquire →
P3751-660-01 STARTER (24V-7.5kW) 2 parts
Ref Part No. Name Qty 0500 37566-55200 STARTER ASSY 1 Enquire → 0800 F1805-12035 BOLT,W/WASHER, B/W 3 Enquire →
P3751-660-02 STARTER (ASSY) 25 parts
Ref Part No. Name Qty 0500 37566-55200 STARTER ASSY 1 Enquire → 0500020 37566-40211 ARMATURE ASSY 1 Enquire → 0500030 37566-40222 BEARING,BALL 1 Enquire → 0500040 10456-62007 BEARING,BALL 1 Enquire → 0500050 32666-20411 YOKE ASSY 1 Enquire → 0500060 37566-55212 BRACKET ASSY,FRONT 1 Enquire → 0500070 37566-55213 METAL 1 Enquire → 0500080 37566-40212 LEVER,SHIFT 1 Enquire → 0500090 37566-40213 PIN,LEVER 1 Enquire → 0500100 37566-00127 CLUTCH ASSY 1 Enquire → 0500110 37566-30118 SHAFT ASSY 1 Enquire → 0500120 37566-40223 BEARING,BALL 1 Enquire → 0500130 37566-00126 STOPPER,PINION 1 Enquire → 0500140 37566-00125 CLIP,RING 1 Enquire → 0500150 37566-10312 BRACKET ASSY,CENTER 1 Enquire → 0500160 37566-00222 BRACKET,CENTER 1 Enquire → 0500170 32666-20412 BRACKET ASSY,REAR 1 Enquire → 0500180 32666-20413 HOLDER,BRUSH 1 Enquire → 0500190 32666-20414 SPRING,BRUSH 4 Enquire → 0500200 37566-40217 BRUSH 4 Enquire → 0500210 32666-20415 SWITCH ASSY 1 Enquire → 0500220 32666-20416 WIRE,LEAD 1 Enquire → 0500230 32666-20417 SWITCH ASSY 1 Enquire → 0500240 32666-20418 BOLT ASSY 1 Enquire → 0500250 37766-40317 SEAL ASSY 1 Enquire →
P3751-680-01 ALTERNATOR (24V-35A) 17 parts
Ref Part No. Name Qty 3180 F1035-10040 BOLT 1 Enquire → 3190 F1035-12030 BOLT 2 Enquire → 3200 F1035-12060 BOLT 1 Enquire → 3210 F1035-14030 BOLT 1 Enquire → 3220 F1035-14050 BOLT 1 Enquire → 3230 F2320-14000 NUT,JAM 1 Enquire → 3240 F2500-14000 WASHER,PLAIN 2 Enquire → 3250 F2515-10000 WASHER,SPRING 1 Enquire → 3260 F2515-12000 WASHER,SPRING 3 Enquire → 3270 F2515-14000 WASHER,SPRING 2 Enquire → 3280 04344-05101 ALTERNATOR ASSY 1 Enquire → 3290 09413-01401 NUT,LOCK 1 Enquire → 3300 37549-06520 V-BELT,RAW EDGE, L=1355 1 Enquire → 3310 37568-19200 CONNECTOR 1 Enquire → 3320 37568-09300 CONNECTOR 1 Enquire → 3330 45R68-10101 BRACKET,ALTERNATOR 1 Enquire → 3340 45R68-10200 ROD,ADJUSTING 1 Enquire →
P3751-680-02 ALTERNATOR (ASSY) 3 parts
P3751-680-03 ALTERNATOR (HEAT SINK) 3 parts
P3751-710 TURNING GEAR 6 parts
P3751-875 STOP CONTROL HANDLE 20 parts
Ref Part No. Name Qty 0100 04400-02200 SOLENOID 1 Enquire → 0110 F1805-06020 BOLT,W/WASHER, B/W 4 Enquire → 0400 37587-14400 LEVER,STOP 1 Enquire → 0510 F1805-10040 BOLT,W/WASHER 1 Enquire → 0610 32561-28300 PLATE,END 1 Enquire → 0810 F8007-06200 BEARING,BALL 2 Enquire → 0910 F3202-03000 RING,SNAP 1 Enquire → 1010 37587-04202 BRACKET,LEVER 1 Enquire → 1011 F1035-12075 BOLT 2 Enquire → 1012 F2515-12000 WASHER,SPRING 2 Enquire → 1200 37587-00900 FOLLOWER 1 Enquire → 1310 F2515-06000 WASHER,SPRING 1 Enquire → 1500 35A61-58302 L-JOINT 1 Enquire → 1510 35A61-58402 L-JOINT 1 Enquire → 1550 05634-00610 NUT,SELF LOCKING 2 Enquire → 1600 05902-06130 ROD 1 Enquire → 1700 09413-00600 NUT,LOCK 1 Enquire → 1850 F2320-06000 NUT,JAM 1 Enquire → 1913 F2515-12000 WASHER,SPRING 5 Enquire → 1920 45727-31302 BRACKET,SOLENOID 1 Enquire →
P3751-910 TOOL 30 parts
Ref Part No. Name Qty 0200 32591-10010 TOOL ASSY 1 Enquire → 0200010 MC420083 BOX,TOOL 1 Enquire → 0200020 F9614-17000 SOCKET, FOR M12 BOLT 1 Enquire → 0200030 F9614-22000 SOCKET, FOR M14 BOLT 1 Enquire → 0200040 F9614-24000 SOCKET, FOR M16 BOLT 1 Enquire → 0200050 F9614-27000 SOCKET, FOR M18 BOLT 1 Enquire → 0200060 F9614-30000 SOCKET, FOR M20 BOLT 1 Enquire → 0200070 F9614-32000 SOCKET, FOR M22 BOLT 1 Enquire → 0200080 F9615-25000 BAR,EXTENSION 1 Enquire → 0200090 F9617-10000 JOINT,UNIVERSAL 1 Enquire → 0200100 F9618-30000 HANDLE,SLIDE 1 Enquire → 0200110 F9600-07008 SPANNER,OPEN ENDED, 07X08 1 Enquire → 0200120 F9600-10012 SPANNER,OPEN ENDED, 10X12 1 Enquire → 0200130 F9600-14017 SPANNER,OPEN ENDED, 14X17 1 Enquire → 0200140 F9600-19022 SPANNER,OPEN ENDED, 19X22 1 Enquire → 0200150 F9600-24027 SPANNER,OPEN ENDED, 24X27 1 Enquire → 0200160 F9600-30032 SPANNER,OPEN ENDED, 30X32 1 Enquire → 0200170 F9600-36041 SPANNER,OPEN ENDED, 36X41 1 Enquire → 0200180 91267-00201 DRIVER,SCREW 1 Enquire → 0200200 F9630-15000 PLIER 1 Enquire → 0200210 05312-00201 PUMP,GREASE 1 Enquire → 0200211 05312-00700 PUMP 1 Enquire → 0200212 05312-00800 NOZZLE 1 Enquire → 0200220 30091-06501 GAGE,THICKNESS 1 Enquire → 0200230 33491-13600 ADAPTER, FOR TORQUE WRENCH 1 Enquire → 0200240 33491-23500 SOCKET 1 Enquire → 0300 33591-10101 REMOVER 1 Enquire → 1650 32591-22100 WRENCH,FILTER 1 Enquire → 1900 37191-03300 HANDLE 1 Enquire → 2200 42788-00400 CAN,OIL 1 Enquire →
P3751-930 NAME PLATE 11 parts
Ref Part No. Name Qty 0200 00665-04048 RIVET,SCREW 4 Enquire → 0400 32593-00300 PLATE,CAUTION, ENGINE VIEW 1 Enquire → 0700 37593-21300 PLATE,CAUTION, FIRING ORDER 1 Enquire → 0790 37893-06900 PLATE,DIESEL ENGINE 1 Enquire → 0800 * PLATE,NAME, IMO2 1 Enquire → 1500 45A93-50600 LABEL,CAUTION, HOT WATER 1 Enquire → 1510 45A93-50800 LABEL,CAUTION, ROTATING PARTS 2 Enquire → 1520 45A93-50900 LABEL,CAUTION, HOT SURFACE 1 Enquire → 1530 45A93-51200 LABEL,CAUTION, MOVING PARTS 1 Enquire → 1540 45A93-51300 LABEL,CAUTION, OIL MIST 1 Enquire → 1550 45A93-51600 LABEL,CAUTION, OPERATION MANUAL 1 Enquire →
P3751-940-01 SPARE PARTS 11 parts
Ref Part No. Name Qty 0100 37504-66200 O-RING,ROCKER COVER 2 Enquire → 0200 37549-06590 V-BELT,RAW EDGE, L=1535 1 Enquire → 0280 37560-08400 TIP ASSY,NOZZLE 3 Enquire → 0400 37561-16800 GASKET,NOZZLE 6 Enquire → 0470 32562-70300 ELEMENT,FUEL FILTER 2 Enquire → 0500 37540-21100 ELEMENT,OIL FILTER 2 Enquire → 0600 37540-12100 CARTRIDGE,BY-PASS FILTER 1 Enquire → 0650 37540-18511 ELEMENT,OIL FILTER 1 Enquire → 0700 37549-06520 V-BELT,RAW EDGE, L=1355 1 Enquire → 0800 47302-52190 ELEMENT,OIL FILTER 1 Enquire → 0900 45B53-10201 IMPELLER 1 Enquire →
3759443220-0153 COMMON USE (ENGINE BODY) 38 parts
Ref Part No. Name Qty 0100 37594-43220 GASKET KIT,OVERHAUL, COMMON USE 1 Enquire → 0100001 37501-12200 GASKET,CYLINDER HEAD 6 Enquire → 0100002 33504-10300 SEAL,VAVLE STEM 24 Enquire → 0100003 37504-41200 PACKING,ROCKER CASE 6 Enquire → 0100004 37504-66200 O-RING,ROCKER COVER 6 Enquire → 0100005 05507-10200 O-RING 6 Enquire → 0100006 37504-02300 O-RING 6 Enquire → 0100007 37107-04201 O-RING,CYLINDER LINER 6 Enquire → 0100008 37107-04300 O-RING,CYLINDER LINER 12 Enquire → 0100009 37507-32400 O-RING,CYLINDER LINER 6 Enquire → 0100013 05507-10340 O-RING,WATER GALLERY 3 Enquire → 0100014 05946-01201 WASHER,SEALING, SIDE BOLT 7 Enquire → 0100015 37507-16401 O-RING,SIDE COVER 6 Enquire → 0100016 37507-16501 O-RING,CAM ROOM 6 Enquire → 0100017 05507-20400 O-RING 1 Enquire → 0100018 37507-04900 PACKING,CAM ROOM 2 Enquire → 0100019 35B36-02900 GASKET,OIL 2 Enquire → 0100021 32525-23200 PACKING, NOT SHOWN 1 Enquire → 0100022 37511-30200 PACKING, NOT SHOWN 1 Enquire → 0100023 37511-13200 PACKING 1 Enquire → 0100024 37511-35200 PACKING,REAR PLATE 1 Enquire → 0100025 37511-30400 PACKING,TIMING GEAR CASE 1 Enquire → 0100026 05946-02401 WASHER,SEALING 1 Enquire → 0100027 05507-21250 O-RING,PUMP COVER 1 Enquire → 0100031 37213-10700 PACKING,SIDE COVER 2 Enquire → 0100032 37513-10200 PACKING,OIL PAN 1 Enquire → 0100033 05946-02001 WASHER,SEALING 3 Enquire → 0100034 05946-03601 WASHER,SEALING 2 Enquire → 0100035 05507-20600 O-RING 2 Enquire → 0100036 37525-40200 PACKING,FRONT COVER 1 Enquire → 0100037 05507-20900 O-RING 1 Enquire → 0100038 37525-03600 O-RING,REAR DRIVE CASE 1 Enquire → 0100039 F3153-25000 O-RING, NOT SHOWN 1 Enquire → 0100040 30625-50502 GASKET 1 Enquire → 0100066 05946-01601 WASHER,SEALING 1 Enquire → 0100068 33442-20200 PACKING 1 Enquire → 0100110 37504-00900 SEAL,EXHUAST VALVE STEM, DOUBLE SPRING TYPE 12 Enquire → 0100111 37707-17200 PACKING,SIDE COVER 1 Enquire →
3759443220-0253 COMMON USE (AIR SYSTEM) 14 parts
Ref Part No. Name Qty 0100041 35A30-00100 O-RING,JOINT 2 Enquire → 0100042 37530-00200 PACKING,INLET PORT 6 Enquire → 0100043 37530-11201 PACKING,AIR DUCT 1 Enquire → 0100046 37530-20500 PACKING,AIR HEATER 6 Enquire → 0100047 37532-09500 GASKET,EXHAUST MANIFOLD 6 Enquire → 0100048 41232-03900 GASKET,SCREW PLUG 3 Enquire → 0100049 32532-01700 GASEKT,JOINT 4 Enquire → 0100050 35A32-30100 GASKET,TURBO, TD13 1 Enquire → 0100051 37533-03100 GASEKT,TURBO, TD15 1 Enquire → 0100052 49162-51100 O-RING 1 Enquire → 0100053 49181-22600 O-RING 1 Enquire → 0100054 49181-22700 O-RING 1 Enquire → 0100094 37555-10300 GASKET,AIR COOLER 2 Enquire → 0100112 36230-50800 GASKET,AIR COOLER INLET 1 Enquire →
3759443220-0353 COMMON USE (OIL SYSTEM) 25 parts
Ref Part No. Name Qty 0100014 05946-01201 WASHER,SEALING 2 Enquire → 0100017 05507-20400 O-RING 3 Enquire → 0100019 35B36-02900 GASKET,OIL 1 Enquire → 0100055 37536-11100 PACKING, OLD 1 Enquire → 0100056 05507-20450 O-RING 2 Enquire → 0100057 05507-20500 O-RING 1 Enquire → 0100058 05507-20650 O-RING, NEW 1 Enquire → 0100059 05507-10180 O-RING 3 Enquire → 0100060 35C36-02900 PACKING 1 Enquire → 0100061 36236-10800 PACKING, OLD 1 Enquire → 0100062 37536-12700 PACKING 1 Enquire → 0100063 05507-10100 O-RING, OLD 2 Enquire → 0100064 05507-10110 O-RING, OLD 2 Enquire → 0100065 05946-01401 WASHER,SEALING 2 Enquire → 0100066 05946-01601 WASHER,SEALING 2 Enquire → 0100067 05507-20300 O-RING, NEW 1 Enquire → 0100068 33442-20200 PACKING,OIL FILLER 1 Enquire → 0100069 37539-10200 PACKING,OIL COOLER 1 Enquire → 0100070 37539-00400 O-RING 3 Enquire → 0100072 MH035093 O-RING 2 Enquire → 0100073 MH035626 O-RING 4 Enquire → 0100074 MH035092 O-RING 8 Enquire → 0100075 05507-20750 O-RING 1 Enquire → 0100076 05507-10420 O-RING 1 Enquire → 0100077 05507-20600 O-RING 1 Enquire →
3759443220-0453 COMMON USE (COOLING SYSTEM) 21 parts
3759443220-0553 COMMON USE (FUEL SYSTEM) 13 parts
3759443220-0653 COMMON USE (OTHER DEVISE) 2 parts
3759458131-0110 MARINE ADDITIONAL PARTS (ENGINE BODY) 4 parts
Ref Part No. Name Qty 0300 37594-58131 GASKET KIT,OVERHAUL, MARINE ADD. PARTS 1 Enquire → 0300003 05946-03001 WASHER,SEALING, NOT SHOWN 1 Enquire → 0300017 37513-28400 PACKING, NOT SHOWN 2 Enquire → 0300023 37555-10600 PACKING,AIR COOLER 1 Enquire →
3759458131-0210 MARINE ADDITIONAL PARTS (AIR SYSTEM) 2 parts
Ref Part No. Name Qty 0300045 41232-03900 GASKET,EXHAUST MANIFOLD 6 Enquire → 0300056 05946-02401 WASHER,SEALING, OLD 1 Enquire →
3759458131-0310 MARINE ADDITIONAL PARTS (OIL SYSTEM) 18 parts
Ref Part No. Name Qty 0300001 04826-28040 PACKING 1 Enquire → 0300004 04826-28050 PACKING,BREATHER PIPE 2 Enquire → 0300005 35B36-02900 GASKET,EMERGENCY OIL 2 Enquire → 0300012 33336-20500 PACKING 1 Enquire → 0300015 36240-15700 GASKET, NOT SHOWN 1 Enquire → 0300016 36240-15600 GASKET,COVER 1 Enquire → 0300028 42784-02400 PACKING,WING PUMP 2 Enquire → 0300034 F3150-01600 O-RING,COVER 2 Enquire → 0300035 F3150-04200 O-RING,BREATHER ELEMENT 1 Enquire → 0300037 F3156-02500 O-RING,MARINE GEAR DRAIN 1 Enquire → 0300038 F3153-03000 O-RING,TURBO DRAIN PIPE, NOT SHOWN 1 Enquire → 0300048 F4202-24000 GASKET,OIL FILTER ALARM 1 Enquire → 0300049 F3156-04000 O-RING,OIL COOLER COVER 3 Enquire → 0300050 F3156-04500 O-RING,EMERGENCY OIL 3 Enquire → 0300051 F3156-05000 O-RING,EMERGENCY OIL 2 Enquire → 0300052 F3156-07500 O-RING,OIL COOLER COVER 1 Enquire → 0300053 05507-00180 O-RING,OIL COOLER COVER 1 Enquire → 0300056 05946-02401 WASHER,SEALING 1 Enquire →
3759458131-0410 MARINE ADDITIONAL PARTS (COOLING SYSTEM) 36 parts
Ref Part No. Name Qty 0300002 04826-28065 PACKING,WATER INLET PIPE 1 Enquire → 0300006 32546-46800 GASKET,HEAT EXCHANGER 1 Enquire → 0300007 32546-16700 PACKING 2 Enquire → 0300008 32546-17700 PACKING,HEAT EXCHANGER 2 Enquire → 0300009 32546-17900 PACKING 4 Enquire → 0300010 32546-19800 PACKING,HEAT EXCHANGER 2 Enquire → 0300011 32546-20300 PACKING,WATER PIPE 2 Enquire → 0300013 33652-10500 PACKING, NOT SHOWN 1 Enquire → 0300014 33652-10600 PACKING, NOT SHOWN 1 Enquire → 0300018 37555-18113 GASKET 1 Enquire → 0300019 05507-10600 O-RING,AIR COOLER 4 Enquire → 0300020 05507-20900 O-RING,AIR COOLER 2 Enquire → 0300021 37555-28500 GASKET,AIR COOLER 2 Enquire → 0300022 37555-23400 GASKET,AIR COOLER 2 Enquire → 0300024 42702-01100 PACKING, NOT SHOWN 1 Enquire → 0300025 45151-83701 PACKING 2 Enquire → 0300027 42783-07501 PACKING, NOT SHOWN 1 Enquire → 0300030 42783-00117 GASKET,SEA WATER PUMP 1 Enquire → 0300031 42783-00131 GASKET,SEA WATER PUMP 1 Enquire → 0300032 F3153-12500 O-RING,SEA WATER PUMP 1 Enquire → 0300033 42783-00143 O-RING,SEA WATER PUMP 1 Enquire → 0300036 F3153-08000 O-RING,HEAT EXCHANGER 4 Enquire → 0300039 F3153-09000 O-RING,AIR COOLER 1 Enquire → 0300040 F3153-10000 O-RING,WATER INLET PIPE 1 Enquire → 0300041 F3153-20000 O-RING,HEAT EXCHANGER 1 Enquire → 0300042 F3153-07000 O-RING,SEA WATER PIPING 3 Enquire → 0300043 F3153-08500 O-RING, NOT SHOWN 1 Enquire → 0300044 F3153-19000 O-RING, NOT SHOWN 1 Enquire → 0300046 F4202-10000 GASKET,BOOCON PIPE 1 Enquire → 0300054 05946-01601 WASHER,SEALING 3 Enquire → 0300055 05946-02001 WASHER,SEALING 4 Enquire → 0300057 45352-74801 PACKING,THERMO CASE 1 Enquire → 0300058 45352-74901 PACKING,HEAT EXCHANGER 2 Enquire → 0300059 45352-74601 PACKING,SQUARE 3 Enquire → 0300060 45352-74701 PACKING,ZINC ASSY 5 Enquire → 0300061 45352-76400 PACKING,WATER OUTLET PIPE 1 Enquire →
3759458131-0610 MARINE ADDITIONAL PARTS (OTHER DEVISE) 5 parts
Ref Part No. Name Qty 0300026 42796-01300 GASKET,EXHAUST JOINT 2 Enquire → 0300028 42784-02400 PACKING,WING PUMP 2 Enquire → 0300029 42785-04600 PACKING, NOT SHOWN 1 Enquire → 0300046 F4202-10000 GASKET,BOOCON PIPE 1 Enquire → 0300047 F4202-12000 GASKET,BOOCON SENSOR 1 Enquire →
P45R2-370 WING PUMP 34 parts
Ref Part No. Name Qty 0100 42784-00101 PUMP,WING 1 Enquire → 0400 37536-18500 BRACKET 1 Enquire → 0500 37536-08600 BRACKET 1 Enquire → 0600 F1035-10045 BOLT 1 Enquire → 0700 F1035-10050 BOLT 1 Enquire → 0800 F2300-10000 NUT 2 Enquire → 0900 F2515-10000 WASHER,SPRING 2 Enquire → 1000 42790-04920 PIPE,OIL 2 Enquire → 1100 42784-02400 PACKING 2 Enquire → 1200 42784-01700 COCK,THREE WAY 2 Enquire → 1300 37536-48700 PIPE,OIL DRAIN 1 Enquire → 1450 35A46-09400 CLAMP 1 Enquire → 1500 37536-38900 PIPE,OIL PRIMING 1 Enquire → 1600 37536-16300 PIPE,OIL 1 Enquire → 1700 37536-09100 PIPE,DRAIN 1 Enquire → 1800 37536-06400 VALVE,CHECK 1 Enquire → 1900 F4540-18000 CONNECTOR 1 Enquire → 2000 F4560-18000 ELBOW 3 Enquire → 2200 F1035-12045 BOLT 2 Enquire → 2210 F2515-12000 WASHER,SPING 2 Enquire → 2250 F2500-10000 WASHER,PLAIN 2 Enquire → 2600 32597-08600 CLIP 6 Enquire → 2700 45R37-11700 TAPE,RUBBER 7 Enquire → 2800 F1035-12025 BOLT 1 Enquire → 2900 F2515-12000 WASHER,SPRING 1 Enquire → 2910 30668-52600 SPACER 2 Enquire → 2920 F1805-12025 BOLT,W/WASHER, B/W 1 Enquire → 3400 F5006-26000 PLUG,TAPERED 1 Enquire → 4000 45R37-13700 STAY,OIL PIPE 2 Enquire → 4010 F1035-12040 BOLT 2 Enquire → 4020 F2515-12000 WASHER,SPRING 2 Enquire → 4030 F2300-12000 NUT 2 Enquire → 4040 65817-00800 COLLAR 2 Enquire → 4050 F1805-12045 BOLT,W/WASHER, B/W 2 Enquire →
P45R1-613 LEAK OFF PIPE (OUTLET) 1 part
Ref Part No. Name Qty 0100 45950-51900 PIPE,FLEXIBLE 1 Enquire →
P45R1-870 SPEED CONTROL 27 parts
Ref Part No. Name Qty 0100 39A87-11017 CABLE,GOVERNOR 1 Enquire → 0200 45727-32100 BRACKET 1 Enquire → 0300 45387-78700 STAY,CABLE 1 Enquire → 0400 F1035-12055 BOLT 2 Enquire → 0500 F1035-12050 BOLT 1 Enquire → 0600 45188-12800 CLAMP,CONDUIT 1 Enquire → 0700 F1600-05010 SCREW,MACHINE 4 Enquire → 0800 F2515-05000 WASHER,SPRING 4 Enquire → 0900 45387-78500 LEVER,CONTROL 1 Enquire → 1000 F1805-08025 BOLT,W/WASHER, B/W 1 Enquire → 1100 45727-32700 FITTING,WIRE 1 Enquire → 1200 F1805-06016 BOLT,W/WASHER, B/W 1 Enquire → 1300 45188-12700 FITTING 2 Enquire → 1400 F1035-05016 BOLT 2 Enquire → 1500 F2300-05000 NUT 2 Enquire → 1600 45723-39900 SLEEVE 1 Enquire → 1700 45387-78602 BRACKET,CABLE 1 Enquire → 1800 F1035-12050 BOLT 2 Enquire → 1900 47501-31100 SPRING,RETURN 1 Enquire → 2000 45686-39400 BOLT,ADJUSTING 1 Enquire → 2100 F2300-10000 NUT 1 Enquire → 2200 45288-74501 JOINT,BALL 1 Enquire → 2300 45188-11400 CLAMP 1 Enquire → 2400 45188-11500 CLAMP 2 Enquire → 2500 F1600-05020 SCREW,MACHINE 2 Enquire → 2600 F2300-05000 NUT 2 Enquire → 2700 F2515-05000 WASHER,SPRING 2 Enquire →
P45R1-900-01 INSTRUMENT (COMMON PARTS) 53 parts
Ref Part No. Name Qty 0710 44N45-64120 PANEL,GAUGE HARNESS 1 Enquire → 0720 44N45-64420 PANEL,GAUGE HARNESS 1 Enquire → 0730 44N48-54300 HARNESS,PANEL, ENGINE-E/R PANEL 1 Enquire → 0740 44N48-54115 HARNESS,PANEL, E/R PANEL-W/H PANEL 1 Enquire → 0750 45B90-23210 HARNESS,EMERGENCY 1 Enquire → 1060 04442-34410 SWITCH,THERMO, ON 95ﾟC 1 Enquire → 1061 04442-38910 SWITCH,THERMO, ON 88ﾟC 1 Enquire → 1090 45600-42902 CONNECTOR 1 Enquire → 1100 04442-45400 SWITCH,OIL PRESSURE, ON 0.15MPa 1 Enquire → 1105 04442-45510 SWITCH,OIL PRESSURE, ON 0.20MPa 1 Enquire → 1140 04827-02100 BUSHING 1 Enquire → 1175 04541-93400 TRANSMITTER,PRESSURE 1 Enquire → 1195 04525-17200 SENDING UNIT,WATER THERMO 1 Enquire → 1205 45689-50401 CONNECTOR 1 Enquire → 1210 F5006-10000 PLUG,TAPERED 1 Enquire → 1270 F1035-06020 BOLT 3 Enquire → 1280 F2300-06000 NUT 3 Enquire → 1290 F2515-06000 WASHER,SPRING 3 Enquire → 1300 42772-04200 DAMPER 1 Enquire → 1310 45951-04040 PIPE,FLEXIBLE 1 Enquire → 1320 F4560-06300 ELBOW 1 Enquire → 1330 42702-52201 BRACKET 1 Enquire → 1340 F1805-12035 BOLT,W/WASHER, B/W 2 Enquire → 1350 45644-47900 MOUNT,OIL PRESSURE UNIT 1 Enquire → 1360 F1035-10025 BOLT 2 Enquire → 1370 F2300-10000 NUT 2 Enquire → 1380 F2515-10000 WASHER,SPRING 2 Enquire → 1410 05317-41500 CLIP, D=15 10 Enquire → 1420 05317-42000 CLIP, D=20 12 Enquire → 1430 05317-42500 CLIP, D=25 8 Enquire → 1440 05317-43000 CLIP, D=30 5 Enquire → 1450 05318-00300 BAND,CLIP, 1.5-45 20 Enquire → 1460 05318-00200 BAND,CLIP, 1.5-32 20 Enquire → 1470 45644-47900 MOUNT,OIL PRESSURE UNIT 1 Enquire → 1480 F1035-10025 BOLT 2 Enquire → 1490 F2300-10000 NUT 2 Enquire → 1500 F2515-10000 WASHER,SPRING 2 Enquire → 1510 42702-51400 PIPE,AIR 1 Enquire → 1520 37136-23601 BOLT,EYE 1 Enquire → 1530 F4202-10000 GASKET 3 Enquire → 1545 04541-93200 TRANSMITTER,PRESSURE 1 Enquire → 1555 04382-70600 RELAY,EMERGENCY 1 Enquire → 1570 F2300-06000 NUT 8 Enquire → 1580 F2500-06000 WASHER,PLAIN 8 Enquire → 1590 F2515-06000 WASHER,SPRING 8 Enquire → 1651 44N48-58430 HARNESS,MAIN 1 Enquire → 1730 04522-34100 THERMOMETER 1 Enquire → 1770 04410-43420 PICKUP,MAGNETIC 1 Enquire → 1780 04410-14200 PICKUP,MAGNETIC 1 Enquire → 1786 44N45-69610 PANEL ASSY,TRIP, RATED SPEED/1600rpm 1 Enquire → 1787 44N45-69620 PANEL ASSY,TRIP, RATED SPEED/1800rpm 1 Enquire → 1800 45R90-26600 HARNESS,TRIP PANEL 1 Enquire → 1810 45R78-41500 HARNESS,TRIP PANEL 1 Enquire →
P45R1-900-02 INSTRUMENT (WITH OIL LEAK SWITCH SPEC.) 39 parts
Ref Part No. Name Qty 8000 45R90-28600 HARNESS 1 Enquire → 8010 45711-54102 TANK,LEVEL SWITCH 1 Enquire → 8020 45711-54301 COVER,TANK 1 Enquire → 8030 32546-16600 PACKING,THERMOSTAT 1 Enquire → 8040 F1805-08020 BOLT,W/WASHER, B/W 4 Enquire → 8060 45711-54600 SWITCH,LEVEL 1 Enquire → 8070 05946-01001 WASHER,SEALING 2 Enquire → 8080 45723-57200 CONNECTOR 1 Enquire → 8090 04390-00700 GROMMET 1 Enquire → 8100 05317-50401 CLAMP 1 Enquire → 8110 05317-50221 CLAMP 1 Enquire → 8125 07783-06018 CONNECTOR 1 Enquire → 8130 45954-00020 PIPE,OIL 2 Enquire → 8140 37561-03700 SPACER 2 Enquire → 8150 F1805-12040 BOLT,W/WASHER, B/W 2 Enquire → 8160 42800-78800 VALVE,MINIATURE 1 Enquire → 8170 45689-50401 CONNECTOR 1 Enquire → 8180 F5006-10000 PLUG,TAPERED 1 Enquire → 8190 47500-34100 CUSHION,RUBBER 4 Enquire → 8200 47500-36700 SPACER 2 Enquire → 8210 37588-06000 WASHER 2 Enquire → 8220 F2515-06000 WASHER,SPRING 2 Enquire → 8230 F2300-06000 NUT 2 Enquire → 8240 F1035-06040 BOLT 2 Enquire → 8250 45727-55800 BRACKET,TANK 1 Enquire → 8270 45724-86100 PIPE,FLEXIBLE 1 Enquire → 8280 45R90-54200 CONNECTOR 1 Enquire → 8290 05317-41200 CLIP 5 Enquire → 8300 36345-04400 SPACER 1 Enquire → 8305 45R90-54300 ELBOW 1 Enquire → 8310 45R90-55600 STAY,FLEXIBLE PIPE 1 Enquire → 8320 F2515-14000 WASHER,SPRING, B/W 1 Enquire → 8330 F1035-14030 BOLT 1 Enquire → 8340 F2515-10000 WASHER,SPRING 1 Enquire → 8350 05978-10010 BOLT 1 Enquire → 8360 53889-05200 SPACER 1 Enquire → 8370 F1035-12060 BOLT 1 Enquire → 8380 F2515-12000 WASHER,SPRING 1 Enquire → 8390 F2500-12000 WASHER,PLAIN 1 Enquire →
P45R1-900-03 INSTRUMENT (WITH SMART CRUISE ASSIST SPEC.) 21 parts
Ref Part No. Name Qty 0005 44N47-55100 MONITOR UNIT,ECO CRUISE 1 Enquire → 0005010 * COVER,MONITOR 1 Enquire → 0005020 44N47-55170 COVER,PROTECT 1 Enquire → 0005030 44N47-55180 BRACKET 1 Enquire → 0010 44N47-55200 UNIT,SENSOR ECO CRUISE 1 Enquire → 0020 44N47-51400 PICKUP,MAGNETIC 1 Enquire → 0030 04525-17200 SENSOR,THERMO 1 Enquire → 0040 04541-93400 TRANSMITTER,PRESSURE 1 Enquire → 0050 04541-93200 TRANSMITTER,PRESSURE 1 Enquire → 0060 04526-63300 THERMOCOUPLE 1 Enquire → 0065 45R90-28500 WIRE,COMP.LEAD 1 Enquire → 0070 44N47-55310 HARNESS 1 Enquire → 0080 44N47-55320 HARNESS 1 Enquire → 0090 44N47-55330 HARNESS 1 Enquire → 0100 44N47-55340 HARNESS 1 Enquire → 0110 04827-02100 BUSHING 1 Enquire → 0120 45689-50401 CONNECTOR 2 Enquire → 0130 04827-81000 PLUG,TAPERED 1 Enquire → 0150 44N47-51900 UNIT,POWER DELAY 1 Enquire → 0160 44N47-55430 CABLE,UNIT POWER 1 Enquire → 0170 44N47-55530 CABLE,UNIT SIGNAL 1 Enquire →
P45R1-925-01 ACCESSORY (COMMON PARTS) 10 parts
P45R1-925-02 ACCESSORY (SEA WATER FILTER) 17 parts
P45R1-925-03 ACCESSORY (WATER SEPARATOR) 10 parts
P45R1-925-04 ACCESSORY (WITH OIL MIST PROTECTOR SPEC.) 11 parts
Ref Part No. Name Qty 1010 45R61-11100 COVER,FUEL FILTER 1 Enquire → 1020 45161-74801 STAY,COVER 2 Enquire → 1030 45R61-11200 COVER,FEED PUMP 1 Enquire → 1040 45R36-11300 STAY,COVER 2 Enquire → 1050 45R36-11200 COVER,OIL FILTER 1 Enquire → 1060 F1805-08014 BOLT,W/WASHER, B/W 8 Enquire → 1070 F2500-08000 WASHER,PLAIN 8 Enquire → 1080 F1035-14020 BOLT 2 Enquire → 1090 F2515-14000 WASHER,SPRING 2 Enquire → 1100 45R36-11100 COVER,TURBOCHARGER 1 Enquire → 1110 41061-04500 TAPE,PROTECTOR 1 Enquire →
Part numbers, availability and pricing are subject to change without notice — confirm the exact part number with OPS before ordering. Rows shaded like this are printed as * in MHI's catalogue: shown for reference but not available as an individual spare part.
Pair the S6R with Smart Cruising Assist for real-time engine monitoring, fuel tracking and maintenance alerts.
Figures on this page are indicative and subject to change without notice — confirm the exact rating and configuration with OPS before specifying.
